BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
n Receiving and transmitting
Receiving:
q Push [
] to turn the power ON.
w Push [CH Up] or [CH Down], or rotate [CH Up/Down]* to
select a channel, in sequence.
e While receiving a call, adjust the audio output level to a
comfortable listening level.
*Simple type only
Transmitting:
Wait for the channel to become clear to avoid interference.
q Take the microphone off hook.
•The‘audible’conditionisselectedandBUSYindicatorlights
green.
•Aprioritychannelmaybeselectedautomatically.
w Wait for the channel to become clear.
•ThechannelisbusywhenBUSYindicatorlightsgreen.
e While pushing and holding [PTT], speak into the micro-
phone at your normal voice level.
r Release [PTT] to receive.
IMPORTANT: To maximize the readability of your signal;
1. Pause briefly after pushing [PTT].
2. Hold the microphone 5 to 10 cm (2 to 4 inches) from
your mouth, then speak into the microphone at a nor-
mal voice level.
D Transmitting notes
• Transmit inhibit function
The transceiver has several inhibit functions which restrict
transmission under the following conditions:
- The channel is in mute condition (‘Inaudible’ condition;
“
” does not appear.)
- The channel is busy.
- Un-matched (or matched) CTCSS is received.
(Depending on the pre-setting)
- Un-matched (or matched) NAC is received.*
(Depending on the pre-setting)
- The selected channel is a ‘receive only’ channel.
*Digital mode operation only.
• Time-out timer
After continuous transmission for the pre-programmed time
period, the time-out timer is activated, causing the trans-
ceiver to stop transmitting.
• Penalty timer
Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.
To Next Page
