Icom IC-FR3100 Service Manual

[RX UNIT][RX UNIT]
IC1 1190000450 S.IC GN2011-Q (TX) T
IC2 1110003490 S.IC TA31136FN (D,EL) T
IC3 1180000420 S.IC TA78L05F (TE12R) T
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER B
IC5 1110002750 S.IC TA75S01F (TE85R) B
IC6 1180000420 S.IC TA78L05F (TE12R) B
IC7 1180000430 S.IC TA78L06F (TE12L) T
IC8 1110003780 S.IC NJM2902V-TE1 T
Q1 1530003820 S.TRANSISTOR 2SC5337QS-T1 T
Q3 1560000670 S.FET 2SK1771 (TE85R) T
Q6 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R) B
Q7 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R) B
Q8 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q9 1530003270 S.TRANSISTOR 2SC4703-T1 SF B
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q15 1520000270 S.TRANSISTOR 2SB1182 TL Q B
Q16 1530002060 S.TRANSISTOR 2SC4081 T106 R B
Q18 1560000540 S.FET 2SK880-Y (TE85R) B
Q19 1590000440 S.TRANSISTOR DTA143ZUA T106 T
Q20 1510000510 S.TRANSISTOR 2SA1576A T106R T
Q21 1530002060 S.TRANSISTOR 2SC4081 T106 R T
D1 1750000070 S.DIODE 1SS226 (TE85R) T
D3 1720000640 S.VARICAP 1SV284 (TPH3) T
D4 1720000640 S.VARICAP 1SV284 (TPH3) T
D6 1720000640 S.VARICAP 1SV284 (TPH3)
[USA3], [GEN3], [GEN7] only T
D7 1720000640 S.VARICAP 1SV284 (TPH3)
[USA3], [GEN3], [GEN7] only T
D15 1750000140 S.DIODE 1SS268 (TE85R) B
D16 1750000140 S.DIODE 1SS268 (TE85R) B
FI1 2030000201 S.MONOLITH FL-349A (70.00 MHz) T
FI5 2020001030 CERAMIC CFWLA455KGFA-B0 T
FI6 2020001010 CERAMIC CFWLA455KFFA-B0
[FRG1], [FRG3] T
2020001040 CERAMIC CFWLA455KEFA-B0 Other T
X1 6070000150 S.DISCRIMINATOR CDBCB455KCAY24-R0 T
X2 6050011470 XTAL CR-729 (69.545 MHz) T
X3 6050011480 S.XTAL CR-732 (12.800 MHz) Other T
6050011680 S.XTAL CR-758 (12.8 MHz)
[USA1], [USA3], [FR4100] T
L1 6200007670 S.COIL LQW2BHN10NJ01L B
L2 6200010290 S.COIL C6328A-22NG-A T
L3 6200010290 S.COIL C6328A-22NG-A T
L4 6200007700 S.COIL LQW2BHN22NJ01L T
L6 6200009700 S.COIL C6328A-28NG-A [L] T
6200010290 S.COIL C6328A-22NG-A [M], [H] T
L7 6200009700 S.COIL C6328A-28NG-A [L] T
6200010290 S.COIL C6328A-22NG-A [M], [H] T
L8 6200010490 S.COIL 458DB-1011=P3 T
L9 6200010490 S.COIL 458DB-1011=P3 T
L10 6200010490 S.COIL 458DB-1011=P3 T
L11 6200008730 S.COIL ELJND R10J B
L14 6200005510 S.COIL ELJND R27J-F T
L20 6200010300 S.COIL ELJND R68JF T
L21 6200007230 S.COIL LQW2BHN15NJ01L B
L22 6200007710 S.COIL LQW2BHN27NJ01L B
L23 6200007680 S.COIL LQW2BHN12NJ01L B
L24 6200007680 S.COIL LQW2BHN12NJ01L B
L25 6200007230 S.COIL LQW2BHN15NJ01L B
L27 6200007230 S.COIL LQW2BHN15NJ01L B
L29 6200007230 S.COIL LQW2BHN15NJ01L B
L30 6200007230 S.COIL LQW2BHN15NJ01L B
L31 6200010300 S.COIL ELJND R68JF B
L32 6200007670 S.COIL LQW2BHN10NJ01L T
L33 6200005510 S.COIL ELJND R27J-F [FR4100] T
6200007340 S.COIL ELJND R22J [FR4000] T
L35 6200007350 S.COIL ELJND R39J [FR4100] T
6200007820 S.COIL ELJND R33J [FR4000] T
L39 6200007680 S.COIL LQW2BHN12NJ01L B
L40 6200010300 S.COIL ELJND R68JF T
L41 6200009940 S.COIL BLM21PG221SN1 T
L42 6910011690 S.COIL ACB1608M-600-T B
L43 6910011690 S.COIL ACB1608M-600-T T
L44 6910011690 S.COIL ACB1608M-600-T B
L45 6910011690 S.COIL ACB1608M-600-T T
L46 6910011690 S.COIL ACB1608M-600-T T
L47 6910011690 S.COIL ACB1608M-600-T T
L48 6910011690 S.COIL ACB1608M-600-T B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
L49 6910011690 S.COIL ACB1608M-600-T T
L50 6910011690 S.COIL ACB1608M-600-T B
L51 6910011690 S.COIL ACB1608M-600-T T
L52 6200007680 S.COIL LQW2BHN12NJ01L B
L53 6200007680 S.COIL LQW2BHN12NJ01L B
L54 6200007300 S.COIL ELJND 68NJF [L], [M] only T
R1 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) T
R2 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R4 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R5 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R6 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R9 7030000140 S.RESISTOR MCR10EZHJ 10 Ω (100) B
R10 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[USA3], [GEN3], [GEN7] only B
R11 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[USA3], [GEN3], [GEN7] only B
R14 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R15 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R19 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R25 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R26 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) [H] B
7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) [L], [M] B
R35 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R36 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) T
R37 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω) T
R39 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R40 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R41 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R43 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R44 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R48 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R49 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R50 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R52 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R53 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R54 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ) T
R55 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R56 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R57 7510001670 S.THRMISTOR NTCG16 4BH 103KT T
R58 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R60 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R61 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R62 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R63 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R64 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R65 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R66 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R67 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R68 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R69 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R70 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R71 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R72 7030000140 S.RESISTOR MCR10EZHJ 10 Ω (100) B
R73 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R74 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R75 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R76 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω) B
R77 7030006060 S.RESISTOR ERJ12YJ100U (10 Ω) B
R81 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
[FR4000] B
7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
[FR4100] B
R84 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R85 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R86 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R87 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R88 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R92 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R93 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R112 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R115 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R116 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R117 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R118 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R119 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R120 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R121 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R122 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R123 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R126 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R127 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R134 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) B
R135 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
5 - 8
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
