9 - 16
The combination of this page and the previous page
shows the unit layout in the same configuration as the
actual P.C. Board.
JACK1 UNIT [FR4100]
¡BOTTOM VIEW
JACK2 UNIT [FR4100]
¡BOTTOM VIEW
to LOGIC UNIT J10
AF GND
DISC OUT
DC GND
AF OUT
AF GND
E MODG
E MOD2
E MOD3
E MODG
E DTCS
E MODG
RSSI
131
J3
+E15V
