6 - 2
¤ CONNECTION
(Loose Coupling)
FREQUENCY COUNTER
(0.1–300 MHz)
MODULATION ANALYZER
(0.1–300 MHz)
STANDARD SIGNAL GENERATOR
(0.1–300 MHz)
OSCILLOSCOPE
(DC to 10 kHz)
ATTENUATOR
(30 dB/60 W)
RF POWER METER
Black
Red
20 A
fuses
DC power supply
DC power cable
<Rear view>
(Detect output)
