7 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R291 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 137.6/127.7
R292 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 144/126
R293 7030004980 S.RES ERJ2GEJ 101 X (100) B 136.5/83.3
R294 7030004980 S.RES ERJ2GEJ 101 X (100) B 136.5/85
R295 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 137.6/122.5
R296 7030000440 S.RES MCR10EZHJ 3.3 k T 118.4/79.6
R297 7030000440 S.RES MCR10EZHJ 3.3 k T 120.2/79.6
R298 7030000440 S.RES MCR10EZHJ 3.3 k T 116.6/79.6
R299 7030004980 S.RES ERJ2GEJ 101 X (100) B 29.1/19.4
R300 7030005530 S.RES ERJ2GEJ 100 X (10) T 47.6/73.1
R301 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 85.6/105.6
R302 7030005590 S.RES ERJ2GEJ 680 X (68) B 135.6/85
R303 7410001150 S.ARY EXB28V471JX T 47.7/68.4
R304 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 84.3/130
R306 7520000260 S.POS PRF18BB471QB1RB B 84.4/104.4
R308 7030005060 S.RES ERJ2GEJ 333 X (33 k)
[USA-01], [EXP-01] T 144/127.7
7030005070 S.RES ERJ2GEJ 683 X (68 k) [EUR-01] T 144/127.7
R309 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 102.2/75.7
R310 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 143.3/120.2
R311 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 145/122.5
R312 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 146.8/120.2
R313 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 103.5/77.8
R314 7030007280 S.RES ERJ2GEJ 331 X (330) T 146/124.4
R315 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 86/128.9
R316 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 11.2/128.2
R317 7030005010 S.RES ERJ2GEJ 681 X (680) B 138.5/94.7
R318 7030003260 S.RES ERJ3GEYJ 330 V (33) B 140.2/90.1
R320 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 15/124.1
R321 7030003370 S.RES ERJ3GEYJ 271 V (270) B 119.6/141.7
R322 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 121.5/143.4
R324 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 31.3/12
R325 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 32.3/12
R326 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 13.2/125.7
R327 7030000260 S.RES MCR10EZHJ 100 (101) B 119.7/132.8
R328 7030000280 S.RES MCR10EZHJ 150 (151) B 139.3/144.3
R331 7030004980 S.RES ERJ2GEJ 101 X (100) T 12/120
R332 7030003370 S.RES ERJ3GEYJ 271 V (270) B 139.5/136
R333 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 137.7/131.9
R334 7030005651 S.RES ERA3YKD 304V (300 k) T 57.8/30.5
R335 7030005871 S.RES ERA3YKD 104V (100 k) T 55.9/29.7
R336 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 12/120.9
R337 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 13.2/120.6
R339 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 12/125.3
R341 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 33.3/12
R342 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.3/56.9
R346 7410001150 S.ARY EXB28V471JX T 43.5/73.8
R347 7030005000 S.RES ERJ2GEJ 471 X (470) T 9.8/132.9
R348 7030000620 S.RES MCR10EZHJ 100 k B 147.2/150.9
R349 7030000620 S.RES MCR10EZHJ 100 k B 26/149.7
R350 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 6.4/131
R352 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 10.2/125.3
R353 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 55.8/56.9
R354 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 123.3/103
R355 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 127.4/102.2
R356 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 9.8/134.5
R357 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 10.1/150.2
R362 7540000290 ABS ERZV10D220
R364 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 65.1/71.2
R365 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 7.4/120.7
R366 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 7/123.5
R367 7030004980 S.RES ERJ2GEJ 101 X (100) T 9.7/117.3
R368 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 8.5/117.8
R369 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 9.7/118.2
R370 7030008280 S.RES ERJ2GEJ 271 X (270) T 6.1/120.7
R371 7030010040 S.RES ERJ2GEJ-JPW T 5/117.3
R372 7030005000 S.RES ERJ2GEJ 471 X (470) T 115.3/15.8
R373 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 115.3/14
R374 7030000140 S.RES MCR10EZHJ 10 (100) T 111.2/12.3
R375 7030010040 S.RES ERJ2GEJ-JPW T 100.1/16.3
R376 7030004980 S.RES ERJ2GEJ 101 X (100) B 62.3/122.2
R378 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 63.2/126.1
R379 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 59.6/126.1
R380 7030007260 S.RES ERJ2GEJ 330 X (33) B 57.8/123.7
R381 7030005570 S.RES ERJ2GEJ 820 X (82) B 61.4/126.1
R424 7410001150 S.ARY EXB28V471JX T 46.3/42.9
R425 7410001150 S.ARY EXB28V471JX T 36.8/23
R426 7410001150 S.ARY EXB28V471JX T 47.8/33.9
R427 7030005000 S.RES ERJ2GEJ 471 X (470) T 25.5/26.7
R428 7410001140 S.ARY EXB28V104JX T 48/22.7
R429 7410001140 S.ARY EXB28V104JX T 49.7/30.2
R430 7410001140 S.ARY EXB28V104JX T 52.3/43.6
R431 7410001150 S.ARY EXB28V471JX T 17.9/40.3
R432 7410001140 S.ARY EXB28V104JX T 15.2/48.2
R433 7410001150 S.ARY EXB28V471JX T 39.6/23
R435 7410001140 S.ARY EXB28V104JX B 39.1/47.8
R436 7410001140 S.ARY EXB28V104JX B 44.3/41.2
R438 7410001140 S.ARY EXB28V104JX B 34.4/47.7
R439 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 37.3/47.8
R440 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 36.4/47.8
R443 7030005000 S.RES ERJ2GEJ 471 X (470) T 60.4/59.2
R444 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 13.5/33.6
R445 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 13.5/36.1
R446 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 13.5/37.4
R447 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 50.2/19.2
R448 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 49.3/19.2
R449 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 39.5/19.2
R450 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 50.2/16.5
R453 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 52.1/14.9
R454 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 94.9/2.7
R455 7030005010 S.RES ERJ2GEJ 681 X (680) B 124.9/2.7
R456 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 109.9/2.7
R467 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 38/44.6
R468 7410001140 S.ARY EXB28V104JX B 31.8/48.5
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R469 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 32.6/44.6
R470 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 10.9/20.2
R471 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 47.7/44.2
R472 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 4.8/36.1
R473 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 46.2/44.6
R474 7030005530 S.RES ERJ2GEJ 100 X (10) B 15.5/55.3
R475 7030005000 S.RES ERJ2GEJ 471 X (470) B 9/56.2
R476 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 15/53.5
R477 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 15/52.6
R478 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 9.1/54.7
R479 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 64.2/69.6
R480 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 15.6/61.5
R481 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 16.5/59.9
R482 7410001150 S.ARY EXB28V471JX T 19.6/45.1
R483 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 31.2/56.5
R484 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 28.8/50.9
R485 7410001150 S.ARY EXB28V471JX T 67.3/96.9
R486 7410001150 S.ARY EXB28V471JX T 63.9/107
R487 7410001150 S.ARY EXB28V471JX T 73/106.9
R488 7030005000 S.RES ERJ2GEJ 471 X (470) T 9.5/54.9
R489 7030004980 S.RES ERJ2GEJ 101 X (100) B 24.1/58.7
R490 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 28.2/58.4
R491 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.1/51.2
R492 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 29.8/58.8
R493 7030010040 S.RES ERJ2GEJ-JPW T 11.3/19
R494 7030005000 S.RES ERJ2GEJ 471 X (470) T 73.3/99
R495 7030008270 S.RES RR0510P-104-D (100 k) T 54.9/55.3
R496 7030006020 S.RES RR0510P-682-D (6.8 k) T 52.7/56.2
R497 7030008250 S.RES RR0510P-562-D (5.6 k) T 52.7/55.3
R498 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 61.4/103.1
R499 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.4/57
R500 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 21.2/57.5
R501 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 22.8/53.8
R502 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28/55
R503 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 55.6/58.9
R504 7030011920 S.RES RR0510P-561-D (560) T 52.7/54.4
R505 7030010040 S.RES ERJ2GEJ-JPW T 113.4/18.3
R506 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 113.4/19.3
R507 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 115/19.3
R508 7030010040 S.RES ERJ2GEJ-JPW B 93.7/42.6
R509 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 33.3/15.2
R510 7030007350 S.RES ERJ2GEJ 393 X (39 k) B 29/14.1
R511 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 29.1/18.5
R512 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 30.8/18.5
R513 7030007280 S.RES ERJ2GEJ 331 X (330) B 72.6/91
R530 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 62.5/66.3
R532 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.1/37.1
R533 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 57.2/18.4
R534 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 45.3/58.6
R535 7030004980 S.RES ERJ2GEJ 101 X (100) B 56.7/56.9
R536 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 55.8/58.6
R537 7030010040 S.RES ERJ2GEJ-JPW B 41.6/41.2
R539 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 64.2/71.2
R540 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 90.6/17.9
R541 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 28.9/55
R542 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 70.4/65.1
R545 7030010040 S.RES ERJ2GEJ-JPW T 61.2/98.7
R546 7030010040 S.RES ERJ2GEJ-JPW T 61.2/99.6
R547 7030010040 S.RES ERJ2GEJ-JPW T 69.7/99.1
C1 4030017420 S.CER ECJ0EC1H470J B 120.7/39
C2 4030017420 S.CER ECJ0EC1H470J B 22.9/78.1
C3 4030016930 S.CER ECJ0EB1A104K B 130.8/50.2
C4 4030017420 S.CER ECJ0EC1H470J B 121.9/37.1
C5 4030017420 S.CER ECJ0EC1H470J B 21.7/77.1
C6 4030016930 S.CER ECJ0EB1A104K B 52.4/77.9
C7 4030017420 S.CER ECJ0EC1H470J B 122.8/37.1
C8 4030017420 S.CER ECJ0EC1H470J B 21.7/75.5
C9 4030017460 S.CER ECJ0EB1E102K T 17.6/59
C10 4030016930 S.CER ECJ0EB1A104K B 55.7/77.9
C11 4030016930 S.CER ECJ0EB1A104K B 123.7/37.1
C12 4030016930 S.CER ECJ0EB1A104K B 22.1/74.3
C13 4030016930 S.CER ECJ0EB1A104K B 55.6/80.7
C14 4030017460 S.CER ECJ0EB1E102K T 16.1/59.9
C15 4030016930 S.CER ECJ0EB1A104K T 62.4/67.5
C16 4030017620 S.CER ECJ0EC1H100C T 56.1/64.5
C17 4030016930 S.CER ECJ0EB1A104K B 115.5/40.6
C18 4030017430 S.CER ECJ0EC1H101J T 62.4/71.2
C19 4030016930 S.CER ECJ0EB1A104K B 22.9/80.3
C20 4550006250 S.TAN TEESVA 1A 106M8R B 115.3/37.5
C21 4550006250 S.TAN TEESVA 1A 106M8R B 21.3/80.5
C22 4030016930 S.CER ECJ0EB1A104K B 50/77.9
C23 4030016930 S.CER ECJ0EB1A104K T 57.8/52.6
C24 4030016930 S.CER ECJ0EB1A104K B 50.3/81.1
C25 4030016930 S.CER ECJ0EB1A104K B 54.4/81.1
C26 4030017460 S.CER ECJ0EB1E102K B 117.8/39.2
C27 4030017460 S.CER ECJ0EB1E102K B 23.8/80.3
C28 4030016930 S.CER ECJ0EB1A104K B 53.3/77.9
C30 4030017460 S.CER ECJ0EB1E102K T 59.8/67
C31 4030016930 S.CER ECJ0EB1A104K T 60.5/53
C32 4030017590 S.CER ECJ0EC1H070C B 38.4/79.1
C33 4030016930 S.CER ECJ0EB1A104K T 58.9/67
C34 4030017570 S.CER ECJ0EC1H040B B 37.2/78.7
C35 4030016930 S.CER ECJ0EB1A104K B 35.8/75.7
C36 4030017500 S.CER ECJ0EC1H560J B 37.2/79.6
C37 4030016930 S.CER ECJ0EB1A104K B 48.4/79.8
C38 4030016930 S.CER ECJ0EB1A104K B 69.8/78.2
C39 4030017360 S.CER ECJ0EC1H030B B 71.4/77.3
C40 4030017690 S.CER ECJ0EC1H121J B 68.2/76.4
C41 4030018860 S.CER ECJ0EB0J105K B 31/58.2
C42 4030017690 S.CER ECJ0EC1H121J B 66.4/78.2
C43 4030016930 S.CER ECJ0EB1A104K B 55.6/49
C44 4030018860 S.CER ECJ0EB0J105K B 35.7/56.4
