2 - 2
• FRONT UNIT
FRONT CPU
(IC503)
CLOCK OSC
(X501)
LCD DRIVER
(IC500)
ANALOG SW
(IC506)
AF POWER AMP.
(IC509)
SPEAKER SW
(Q508)
