SPECIFICATIONS
11
D GENERAL
• Frequency coverage
TX/RX : 156.300–156.875 MHz
• Mode : 16K0G3E
• Channel spacing : 25 kHz
• Power supply requirement :
<For Survival craft> BP-234
<For on-board use> BP-224 (China version only)
BP-252 (Except China version)
• Current drain (at 7.2 V DC) : TX High (2 W) 1.0 A typical
Max. audio 200 mA typical
• Useable temperature range : –20°C to +55°C
• Frequency stability : ±1.5 kHz (–20°C to +55°C)
• Antenna impedance : 50 Ω
• Dimensions : 65(W) × 145(H) × 44(D) mm
(Projections not included)
• Weight (with BP-234) : Approx. 385 g
D TRANSMITTER
• Output power (at 7.2 V DC) : 2 W (High) and 1 W (Low)
• Modulation system : Variable reactance frequency
modulation
• Microphone impedance : 2 kΩ
• Max. frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : 0.25 µW (below 1 GHz)
1 µW (above 1 GHz)
DRECEIVER
• Receive system : Double-conversion
superheterodyne
• Sensitivity (20 dB SINAD) : –2 dBµ EMF (typical)
• Squelch sensitivity : 0 dBµ EMF (typical)
(at threshold)
• Intermodulation rejection ratio : 68 dB
• Spurious response rejection ratio : 70 dB
• Adjacent channel selectivity : 70 dB
• Audio output power : 0.20 W at 10% distortion with
an 8 Ω load
NOTE: Measurements in according to IEC61097-12.
All stated specifications are subject to change without notice
or obligation�
