Icom IC-M302

[MAIN UNIT]
IC1 1110003490 S.IC TA31136FN (D,EL) T
IC2 1110005320 S.IC NJM13403V-TE1 T
IC3 1110003650 S.IC NJM2211M-TE1 T
IC4 1150002170 IC S-AV35 (I) T
IC6 1110003090 IC LA4425A T
IC7 1140003830 S.IC TC4W66F (TE12L) T
IC8 1130007610 S.IC µPD3140GS-E1 (DS8) T
IC9 1110002020 IC TA7805S T
Q1 1580000540 S.FET 3SK131-T2-LA T
Q2 1580000540 S.FET 3SK131-T2-LA T
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q5 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q11 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q12 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q13 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q15 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q16 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q17 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q18 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q20 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q21 1590000670 S.TRANSISTOR FMW1 T148 T
Q22 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q23 1510000920 S.TRANSISTOR 2SA1577 T106 Q T
Q25 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q26 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q31 1510000920 S.TRANSISTOR 2SA1577 T106 Q T
Q32 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q33 1510000920 S.TRANSISTOR 2SA1577 T106 Q T
Q34 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q35 1520000460 S.TRANSISTOR 2SB1132 T100 R T
Q36 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
D1 1710001080 DIODE XB15A308 T
D2 1710001080 DIODE XB15A308 T
D4 1720000260 S.VARICAP 1SV214 (TPH2) T
D5 1720000260 S.VARICAP 1SV214 (TPH2) T
D6 1720000260 S.VARICAP 1SV214 (TPH2) T
D7 1720000260 S.VARICAP 1SV214 (TPH2) T
D9 1750000470 S.DIODE 1SS321 (TE85R) T
D11 1790000620 S.DIODE MA77 (TX) T
D12 1790000620 S.DIODE MA77 (TX) T
D13 1750000710 S.VARICAP HVC350BTRF T
D14 1750000710 S.VARICAP HVC350BTRF T
D16 1790000620 S.DIODE MA77 (TX) T
D17 1790000620 S.DIODE MA77 (TX) T
D21 1790000690 S.DIODE HSM88ASR-TR T
D22 1790000690 S.DIODE HSM88ASR-TR T
D25 1790000700 DIODE DSA3A1 T
D26 1750000150 S.DIODE DA204K T146 T
FI1 2030000270 MONOLITH FL-363 (21.7 MHz) T
FI2 2030000270 MONOLITH FL-363 (21.7 MHz) T
FI3 2020001680 CERAMIC ALFY450E T
X1 6070000200 DISCRIMINATOR
CDBLA450KCAY24-B0 (CDB450C24) T
X2 6050011760 S.XTAL CR-768 (21.250 MHz) T
L1 6110001600 COIL LA-243 T
L2 6110001600 COIL LA-243 T
L3 6110001600 COIL LA-243 T
L6 6150003820 COIL LS-440 T
L7 6150003820 COIL LS-440 T
L8 6150003820 COIL LS-440 T
L9 6150003820 COIL LS-440 T
L10 6200010090 S.COIL ELJND R82JF T
L12 6200009620 S.COIL MLG1608B 68NJ-T T
L13 6200009620 S.COIL MLG1608B 68NJ-T T
L21 6200003710 S.COIL NL 252018T-2R7J T
L22 6200008190 S.COIL 0.25-1.9-8TL 80N T
L23 6200009560 S.COIL MLG1608B R10J-T T
L26 6200009560 S.COIL MLG1608B R10J-T T
L28 6200009680 S.COIL MLG1608B 47NJ-T T
L29 6200009680 S.COIL MLG1608B 47NJ-T T
L31 6110001670 COIL LA-253 T
L32 6170000230 COIL LW-25 T
L35 6200009560 S.COIL MLG1608B R10J-T T
L36 6200009560 S.COIL MLG1608B R10J-T T
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R5 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
[MAIN UNIT]
R6 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R7 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) T
R8 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R9 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R10 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω) T
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R14 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R16 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R21 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R25 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ) T
R26 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R27 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R28 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R31 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R32 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R33 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) T
R34 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) T
R35 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R36 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R37 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R38 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R41 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R42 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R43 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R44 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R46 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R47 7510001510 S.THERMISTOR NTCG16 4LH 223KT T
R48 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R50 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ) T
R51 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R53 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R57 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R61 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R62 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R63 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R64 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) T
R65 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R66 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R67 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R68 7030003860 S.RESISTOR ERJ3GE JPW V T
R71 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R72 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) T
R73 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R74 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R75 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R76 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R78 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R81 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R82 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R83 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) T
R84 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R85 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) T
R86 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R87 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R88 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R89 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R91 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R92 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R93 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R94 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω) T
R95 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R96 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) T
R97 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R102 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R103 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R106 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R107 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω) T
R108 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R109 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R110 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R111 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R112 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R113 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R116 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R117 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R122 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R123 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R124 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω) T
R126 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) T
R127 7030000340 S.RESISTOR MCR10EZHJ 470 Ω (471) T
R130 7030001110 S.RESISTOR MCR50JZHJ 68 Ω (680) T
R131 7030000420 S.RESISTOR MCR10EZHJ 2.2 kΩ T
R132 7030000420 S.RESISTOR MCR10EZHJ 2.2 kΩ T
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
