Icom IC-M302

[LOGIC BOARD]
[VR BOARD]
R1 7210003140 VARIABLE TP96N97N-15SK-10KA-2685 T
J1 6510009490 CONNECTOR S5B-ZR T
EP1 0910056592 PCB B 6017B
R1 7210003150 VARIABLE TP96N97-15SK-10KB-2685 T
J1 6510009470 CONNECTOR S3B-ZR T
EP1 0910056602 PCB B 6018B
MC1 0800007150 MICROPHONE HM-141B ACC <FG> [Black]
0800007160 MICROPHONE HM-141W ACC <FG> [White]
0800007320 MICROPHONE HM-141G ACC <FG> [Gray]
SP1 2510001240 SPEAKER 045P0803 <FG>
W1 7120000470 JUMPER ERDS2T0
W2 7120000470 JUMPER ERDS2T0
W3 8900012410 CABLE OPC-1263 (N=30,L=110)
IC1 1140011800 S.IC M37560MFA-303GP (FX-2685A) T
IC2 1170000350 S.IC PC357N6T T
IC3 1130007430 S.IC TC7S14FU (TE85R) T
IC4 1130011570 S.IC BR24L32FV-WE2 T
IC5 1110006210 S.IC BD5242FVE-TR T
IC6 1110002700 S.IC NJM2904M-TE1 T
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R T
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q4 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q6 1590001050 S.TRANSISTOR DTC114TUA T106 T
D1 1750000550 S.DIODE 1SS355 TE-17 T
D2 1750000550 S.DIODE 1SS355 TE-17 T
D3 1750000150 S.DIODE DA204K T146 T
X1 6050011800 S.XTAL CR-769 (7.9872 MHz) T
S.=Surface mount
R1 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R3 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R4 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R14 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R15 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R16 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R21 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R22 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R23 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R24 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R25 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R26 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R27 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R28 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R29 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R30 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R31 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R35 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) T
R36 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R37 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R38 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R40 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω) T
R41 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R43 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R51 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R52 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R54 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R61 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R62 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R63 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R64 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R65 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
C1 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C2 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C3 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C4 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C5 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C6 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C7 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C11 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C13 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C16 4030006880 S.CERAMIC C1608 JB 1H 472K-T T
C17 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C18 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C21 4030008880 S.CERAMIC C1608 JB 1H 223K-T T
C22 4510005310 S.ELECTROLYTIC ECEV1CA220SR T
C23 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C25 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C31 4030009650 S.CERAMIC C1608 CH 1H 240J-T T
C32 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C41 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C42 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
J1 6510021720 S.CONNECTOR 30FLT-SM1-TB T
J2 6510015540 S.CONNECTOR B4B-ZR-SM3-TF T
DS1 5030002590 LCD IS08251E00V0 B
DS2 5040002310 S.LED SML-311YTT86 B
DS3 5040002310 S.LED SML-311YTT86 B
DS4 5040002660 S.LED FY1101F-TR (LED) B
DS5 5040002660 S.LED FY1101F-TR (LED) B
DS6 5040002660 S.LED FY1101F-TR (LED) B
DS7 5040002660 S.LED FY1101F-TR (LED) B
EP1 0910057311 PCB B 6096A
EP2 8930061040 LCD CONTACT SRCN-2685-SP-N-W B
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[SQL BOARD]
REF ORDER
DESCRIPTION M.
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION M.
NO. NO.
[LOGIC BOARD]
6-1 IC-M302
