Icom IC-M401E

[LOGIC-E BOARD][MAIN-E UNIT]
C415 4030008470 S.CERAMIC C1608 JB 1H 272K-T B
C416 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
RL1 6330001670 RELAY FTR-P3CP012W1 T
J4 6510018970 S.CONNECTOR B4B-PH-SM3-TB T
J5 6510019420 S.CONNECTOR B8B-ZR-SM3-TF T
J6 6510022470 S.CONNECTOR 40FLT-SM1-TB T
J7 6510015540 S.CONNECTOR B4B-ZR-SM3-TF T
T1 5920000570 TRANSFORMER 12T01 T
W1 7120000470 JUMPER ERDS2T0 T
W2 7120000470 JUMPER ERDS2T0 T
EP1 0910056801 PCB B 6053A
S.=Surface mount
IC1 1140011930 S.IC HD6433847RB82H (FX-2706B) T
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 T
IC3 1130007570 S.IC BU4094BCFV-E2 T
IC4 1130009680 S.IC HN58X2432TI T
IC7 1130005290 S.IC TC74HC14AF T
IC8 1170000350 S.IC PC357N6T T
IC9 1110002700 S.IC NJM2904M-TE1 T
Q1 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R T
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q4 1560000810 S.FET 2SK1069-4-TL T
Q6 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q7 1590000720 S.TRANSISTOR DTA144EUA T106 T
Q8 1530002060 S.TRANSISTOR 2SC4081 T106 R T
Q9 1510000510 S.TRANSISTOR 2SA1576A T106R T
Q11 1590001330 S.TRANSISTOR DTA114EUA T106 T
D1 1750000550 S.DIODE 1SS355 TE-17 T
D2 1750000550 S.DIODE 1SS355 TE-17 T
D3 1730002360 S.ZENER MA8062-M (TX) T
D4 1730002360 S.ZENER MA8062-M (TX) T
D5 1730002360 S.ZENER MA8062-M (TX) T
D6 1730002360 S.ZENER MA8062-M (TX) T
D7 1750000150 S.DIODE DA204K T146 T
X1 6050011500 S.XTAL CR-739 (9.8304 MHz) T
R1 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R2 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R4 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R6 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R7 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R8 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R10 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R11 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) T
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R14 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) T
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R16 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) T
R17 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R18 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R19 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R20 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R21 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R22 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R23 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R24 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) T
R25 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω) T
R26 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω) T
R27 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) T
R28 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R29 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R30 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R31 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R32 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R33 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R34 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R35 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R36 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R37 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R38 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R41 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R42 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R43 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R44 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R46 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R47 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R48 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R49 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R50 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R51 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R52 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R54 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R56 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ) T
R60 7030006041 S.RESISTOR ERA3YED 622V T
R61 7030003860 S.RESISTOR ERJ3GE JPW V T
6 - 4
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
