Icom IC-M401E

[VR BOARD][LOGIC-E BOARD]
R62 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R63 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R64 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R65 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R71 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R72 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R73 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R75 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R77 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R78 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R81 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R82 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R83 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R84 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R85 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R87 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R90 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
C1 4030007060 S.CERAMIC C1608 CH 1H 270J-T T
C2 4030009650 S.CERAMIC C1608 CH 1H 240J-T T
C3 4030008890 S.CERAMIC C1608 JB 1H 273K-T T
C5 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C6 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C7 4550006210 S.TANTALUM ECST1CX106R T
C8 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C9 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C12 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C41 4550006210 S.TANTALUM ECST1CX106R T
C42 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C43 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C72 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C73 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C74 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C75 4030006880 S.CERAMIC C1608 JB 1H 472K-T T
C76 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C82 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C91 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C92 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C94 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C95 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C96 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
J1 6510021440 S.CONNECTOR B6B-ZR-SM3-TF T
J3 6510022190 S.CONNECTOR B3B-PH-SM3-TB T
J4 6510022470 S.CONNECTOR 40FLT-SM1-TB T
DS1 5030001950 LCD TTR5341 B
DS2 5040002310 S.LED SML-311YTT86 B
DS3 5040002310 S.LED SML-311YTT86 B
DS4 5040002310 S.LED SML-311YTT86 B
DS5 5040002310 S.LED SML-311YTT86 B
DS6 5040002660 S.LED FY1101F-TR (LED) B
DS7 5040002660 S.LED FY1101F-TR (LED) B
EP1 0910056810 PCB B 6054
EP2 8930054970 LCD CONTACT SRCN-2438-SP-N-W B
S.=Surface mount
R1 7210002350 VARIABLE TP96N97N15F-10KA-1301 T
W1 8900010820 CABLE OPC-1099 <CMI> T
EP1 0910056781 PCB B 6051A
R1 7210002360 VARIABLE TP96N97-15F-10KB-1301
EP1 0910056791 PCB B 6052A
MC1 0800006232 MICROPHONE HM-132B-2 ACC <KN> [BLACK]
MC1 0800006242 MICROPHONE HM-132W-2 ACC <KN> [WHITE
SP1 2510001240 SPEAKER 045P0803 <FG>
W1 7120000470 JUMPER ERDS2T0
W2 7120000470 JUMPER ERDS2T0
W3 8900010500 CABLE OPC-1046
C1 4020000430 CYLINDER UP050 B 471K-NA-CZ
J1 6510004880 CONNECTOR MR-DS-E 01
W1 8900010710 CABLE OPC-1087 <LIA>
W2 8900010491 CABLE OPC-1041A
W3 7120000470 JUMPER ERDS2T0
6 - 5
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[SQL BOARD]
REF ORDER
DESCRIPTION M.
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION M.
NO. NO.
[CHASSIS UNIT]
