S.=Surface mount
6 - 6
[MAIN UNIT]
R1 7010007640 RESISTOR FRD25 T2-123J (12 kΩ) T
R2 7010007630 RESISTOR FRD25 T2-682J (6.8 kΩ) T
R3 7010007650 RESISTOR FRD25 T2-153J (15 kΩ) T
R4 7010007660 RESISTOR FRD25 T2-333J (33 kΩ) T
C1 4030018550 S.CERAMIC C1608 JB 1H 223K-T T
C2 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
MC1 7700002500 MICROPHONE KUC3523-040245
S1 2260002330 SWITCH SKHHLP014A B
S2 2260002340 SWITCH SKHHAM024A T
S3 2260002340 SWITCH SKHHAM024A T
S4 2260002340 SWITCH SKHHAM024A T
W1 9018490010 WIRE 71/98/010/X98/X98 <KN> T
W2 9018490010 WIRE 71/98/010/X98/X98 <KN> T
W3 9024495010 WIRE 24/00/020/W01/W01 <KN> B
W4 9024495020 WIRE 24/04/020/W01/W01 <KN> B
EP1 0910053701 PCB B-5587A
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-2 HM-132
