PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
i CHANNEL 16/CALL CHANNEL KEY [16/C]
Push to select Channel 16. (p. 11) ➥
Hold down for 1 second to select the Call channel. (p. ➥
11 )
  •“CALL”isdisplayedwhentheCallchannelisselected.
➥ When the Call channel is selected, hold down for 3 sec-
onds to enter Call channel entry mode. (p.
16 )
o SOFTKEYS
Desired functions as described below can be assigned in
the Menu screen.
Scan [
] (p. 20)
Push to start or stop a Normal or Priority scan.
Dualwatch/Tri-watch [
] (p. 21)
Push to start Dualwatch or Tri-watch. ➥
Push to stop Dualwatch or Tri-watch when either is ac- ➥
tivated.
High/Low [
] (p. 14)
Push to set the power to high or low.
 •Somechannelsaresettoonlylowpower.
Channel/Weather channel [ ]* (pp. 11, 13)
Push to selects and toggles the regular channel and
Weather channel.
*For only U.S.A. and Australian version transceivers.
Channel [ ]* (p. 11)
Push to select a regular channel.
* For only IC-M423 and IC-M423G except for Australian version
transceivers.
Public address [ ] (p. 70)
Push to enter the PA (Public Address) mode.
RX Speaker [
] (p. 70)
Push to turn the RX Speaker mode ON or OFF.
Horn [
] (p. 71)
Push to enter the Horn mode.
Intercom [
] (p. 69)
Push to enter the Intercom mode.
LO/DX [
]* (p. 14)
Push to turn the Attenuator function ON or OFF.
 •“LOCAL”isdisplayedwhentheAttenuatorfunctionisON.
*For only U.S.A. and Australian version transceivers.
AquaQuake [ ] (p. 18)
Holding down to activate the AquaQuake to clear water
away from the speaker grill.
