Icom IC-M602 - Page 30

6 - 11
S.=Surface mount
[MAIN UNIT]
C17 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C18 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C22 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C23 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C24 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C25 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C26 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C27 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C28 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C30 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C31 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C32 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C33 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C34 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C35 4510005430
S.ELECTROLYTIC ECEV0JA220SR
C36 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C37 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C38 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C39 4510006220
S.ELECTROLYTIC ECEV1CA101UP
C40 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C41 4510006250 S.ELECTROLYTIC ECEV1CA331UP
C42 4030008890 S.CERAMIC C1608 JB 1H 273K-T
C44 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C45 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C46 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C47 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C51 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C52 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C53 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C54 4030012600 S.CERAMIC C2012 JB 1A 105M-T
J1 6510019420 S.CONNECTOR B8B-ZR-SM3-TF
J2 6510021440 S.CONNECTOR B6B-ZR-SM3-TF
DS1 5030001900 LCD A0119 LCD36*28.5
DS2 5040002660 S.LED FY1101F-TR (LED)
DS3 5040002660 S.LED FY1101F-TR (LED)
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002660 S.LED FY1101F-TR (LED)
DS6 5040002660 S.LED FY1101F-TR (LED)
DS7 5040002310 S.LED SML-311YTT86
DS8 5040002310 S.LED SML-311YTT86
DS9 5040002310 S.LED SML-311YTT86
DS10 5040002310 S.LED SML-311YTT86
MC1 7700002480 MICROPHONE SKB-2746 LPC
S1 2260002710 S.SWITCH SKQLLCE012
S2 2260002710 S.SWITCH SKQLLCE012
S3 2260002710 S.SWITCH SKQLLCE012
S4 2260002710 S.SWITCH SKQLLCE012
EP1 0910053144 PCB B 5526D
EP2 8930051120 LCD CONTACT SRCN-2320-SP-N-W
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R8 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R10 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R11 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R13 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R14 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R15 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R16 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R17 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R18 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R19 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R20 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R21 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R22 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R26 7510001670 S.THERMISTOR NTCG16 4BH 103KT
R27 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R28 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R29 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R30 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R31 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R32 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R33 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R34 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R35 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R43 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R45 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R46 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R47 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R50 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R51 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R52 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R53 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R54 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R55 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R56 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R57 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R58 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R59 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R60 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R61 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R62 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R63 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R64 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R65 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R66 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R67 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R68 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R70 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R75 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R76 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R77 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
C1 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C3 4510005430
S.ELECTROLYTIC ECEV0JA220SR
C4 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C5 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C6 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C7 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C9 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C10 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C11 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C12 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C13 4030008920 S.CERAMIC C1608 JB 1H 473K-T
C14 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C15 4510006220
S.ELECTROLYTIC ECEV1CA101UP
C16 4510006220 S.ELECTROLYTIC ECEV1CA101UP
REF ORDER
DESCRIPTION
NO. NO.
