SECTION 9 BOARD LAYOUTS
9-1 VR BOARD
9-3 DIAL BOARD
9-2 SQL BOARD
GND
1
3
to AF
unit J6
J1
VOL2
VOL1
SQL5V
3
1
to LOGIC
board J7
J1
SQLV
SQLG
GND
5
1
to LOGIC
board J7
J1
DIAL4
DIAL3
DIAL2
DIAL1
9-4 CONNECT UNIT
• TOP VIEW
• BOTTOM VIEW (CONNECT UNIT)
1
2
to AF unit J4
20
19
J4
GND
AF/MIC2
RRXDA2
AF/MIC1
RTADA1
NMEAOUT+
NMEAIN+
NC
VCC VCC
GND
MICG
RTXDA2
PTTC
ICF3
RRXDA1
NMEAIN
-
GND
NC
VCC
SP
-
21
to AF
unit W6
J5
SP+
GPS
COMMAND
MIC1
COMMAND
MIC2
9 - 1
