• UT-112 VOICE SCRAMBLER UNIT INSTALLATION
1 Plug UT-112 into J3 on the AF unit.
• Removing the AF unit
1 Disconnect 4 connectors from J5, J8, J9 and J10.
2 Disconnect 2 flat cables from J2 and J4
3 Unscrew 2 screws H, and remove 2 clips I, J.
4 Unscrew 3 screws K, and remove the AF unit.
3 - 2
