Icom IC-R2 Service Manual

S.=Surface mount
R100 7030008010 S.RESISTOR ERJ2GEJ 123X (12 kΩ)
R101 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R102 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R103 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R104 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R105 7030005590 S.RESISTOR ERJ2GEJ 680 X (68 Ω)
R106 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R108 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R110 7030008010 S.RESISTOR ERJ2GEJ 123X (12 kΩ)
R112 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R116 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R120 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R121 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R123 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R124 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R125 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R128 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R129 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R130 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R131 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R132 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R133 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R134 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R135 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R147 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R151 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R152 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R154 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R156 7030008410 S.RESISTOR ERJ2GEJ 392 X (3.9 kΩ)
R159 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R160 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
R162 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R163 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R169 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R170 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R171 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R172 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R174 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R177 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R179 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R187 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R188 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R196 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R197 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R198 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ)
R199 7030008010 S.RESISTOR ERJ2GEJ 123X (12 kΩ)
R200 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R201 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R202 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R203 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R204 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R205 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R207 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R208 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R209 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
R210 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω)
R215 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω)
R216 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R219 7030009530 S.RESISTOR ERJ2GEJ 270 X (27 Ω)
R220 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R221 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R222 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R223 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R224 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R225 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R226 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R227 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R228 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R229 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R230 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R231 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R232 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R233 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R234 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R235 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
R236 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R237 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
R238 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R239 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R319 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R323 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R324 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R325 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R326 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R327 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
C1 4030014340 S.CERAMIC ECUE1H390JCQ
C2 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C5 4030014220 S.CERAMIC ECUE1E471KBQ
C8 4030014240 S.CERAMIC ECUE1H180JCQ
C9 4030014030 S.CERAMIC ECUE1H2R5BCQ
C10 4030014000 S.CERAMIC ECUE1H1R5BCQ
C11 4030014150 S.CERAMIC ECUE1H220JCQ
C12 4030014180 S.CERAMIC ECUE1H470JCQ
C13 4030014160 S.CERAMIC ECUE1H270JCQ
C14 4030013850 S.CERAMIC ECUE1E102KBQ
C15 4030013980 S.CERAMIC ECUE1H010BCQ
C16 4030013850 S.CERAMIC ECUE1E102KBQ
C18 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C19 4030014130 S.CERAMIC ECUE1H120JCQ
C20 4030014170 S.CERAMIC ECUE1H330JCQ
C21 4030014050 S.CERAMIC ECUE1H030BCQ
C22 4030014100 S.CERAMIC ECUE1H070CCQ
C23 4030014080 S.CERAMIC ECUE1H050BCQ
C27 4030013850 S.CERAMIC ECUE1E102KBQ
C28 4030013850 S.CERAMIC ECUE1E102KBQ
C30 4030013850 S.CERAMIC ECUE1E102KBQ
C32 4030013850 S.CERAMIC ECUE1E102KBQ
C33 4030014170 S.CERAMIC ECUE1H330JCQ
C35 4030014120 S.CERAMIC ECUE1H100CCQ
C36 4030014120 S.CERAMIC ECUE1H100CCQ
C37 4030014030 S.CERAMIC ECUE1H2R5BCQ
C39 4030014070 S.CERAMIC ECUE1H040BCQ
C40 4030014140 S.CERAMIC ECUE1H150JCQ
C41 4030014080 S.CERAMIC ECUE1H050BCQ
C42 4030014060 S.CERAMIC ECUE1H3R5BCQ
C43 4030014200 S.CERAMIC ECUE1H101JCQ
C44 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C45 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C46 4030014050 S.CERAMIC ECUE1H030BCQ
C47 4030014090 S.CERAMIC ECUE1H060CCQ
C48 4030014090 S.CERAMIC ECUE1H060CCQ
C49 4030014050 S.CERAMIC ECUE1H030BCQ
C50 4030013980 S.CERAMIC ECUE1H010BCQ
C51 4030014050 S.CERAMIC ECUE1H030BCQ
C52 4030014220 S.CERAMIC ECUE1E471KBQ
C54 4030013850 S.CERAMIC ECUE1E102KBQ
C55 4030013850 S.CERAMIC ECUE1E102KBQ
C58 4030013850 S.CERAMIC ECUE1E102KBQ
C59 4030014020 S.CERAMIC ECUE1H020BCQ
C60 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C61 4030013850 S.CERAMIC ECUE1E102KBQ
C62 4550006200 S.TANTALUM ECST0JY106R
C63 4030014210 S.CERAMIC ECUE1H151JCQ
C64 4030014140 S.CERAMIC ECUE1H150JCQ
C65 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C66 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C67 4030014170 S.CERAMIC ECUE1H330JCQ
C69 4030013850 S.CERAMIC ECUE1E102KBQ
C70 4030013850 S.CERAMIC ECUE1E102KBQ
C71 4030014070 S.CERAMIC ECUE1H040BCQ
C73 4030013850 S.CERAMIC ECUE1E102KBQ
C74 4030013850 S.CERAMIC ECUE1E102KBQ
C75 4030013850 S.CERAMIC ECUE1E102KBQ
C78 4550006910 S.TANTALUM TESVSP 1C 334M-8R
C79 4030013850 S.CERAMIC ECUE1E102KBQ
C80 4030014180 S.CERAMIC ECUE1H470JCQ
C81 4030013850 S.CERAMIC ECUE1E102KBQ
C82 4550006200 S.TANTALUM ECST0JY106R
C84 4030013850 S.CERAMIC ECUE1E102KBQ
C85 4030014240 S.CERAMIC ECUE1H180JCQ
C86 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C87 4030014180 S.CERAMIC ECUE1H470JCQ
C88 4030014180 S.CERAMIC ECUE1H470JCQ
C89 4030014180 S.CERAMIC ECUE1H470JCQ
C90 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C92 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C93 4030013850 S.CERAMIC ECUE1E102KBQ
C94 4030013850 S.CERAMIC ECUE1E102KBQ
C95 4030013850 S.CERAMIC ECUE1E102KBQ
C96 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C97 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C98 4030014230 S.CERAMIC ECUE1E681KBQ
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
