Icom IC-R2 Service Manual

S.=Surface mount
C99 4030014230 S.CERAMIC ECUE1E681KBQ
C100 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C101 4030014120 S.CERAMIC ECUE1H100CCQ
C102 4030013850 S.CERAMIC ECUE1E102KBQ
C103 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C104 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C105 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C106 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C107 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C108 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C118 4030013850 S.CERAMIC ECUE1E102KBQ
C119 4030013850 S.CERAMIC ECUE1E102KBQ
C121 4030013850 S.CERAMIC ECUE1E102KBQ
C134 4030013850 S.CERAMIC ECUE1E102KBQ
C135 4030013850 S.CERAMIC ECUE1E102KBQ
C136 4030014100 S.CERAMIC ECUE1H070CCQ
C138 4030014220 S.CERAMIC ECUE1E471KBQ
C139 4030014120 S.CERAMIC ECUE1H100CCQ
C141 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C142 4030013850 S.CERAMIC ECUE1E102KBQ
C145 4030014220 S.CERAMIC ECUE1E471KBQ
C147 4030014030 S.CERAMIC ECUE1H2R5BCQ
C148 4030014220 S.CERAMIC ECUE1E471KBQ
C150 4030013850 S.CERAMIC ECUE1E102KBQ
C151 4030014070 S.CERAMIC ECUE1H040BCQ
C153 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C154 4030014120 S.CERAMIC ECUE1H100CCQ
C155 4030014080 S.CERAMIC ECUE1H050BCQ
C156 4030014420 S.CERAMIC ECUE1H0R5BCQ
C158 4030013850 S.CERAMIC ECUE1E102KBQ
C160 4030013850 S.CERAMIC ECUE1E102KBQ
C162 4550006200 S.TANTALUM ECST0JY106R
C163 4030013850 S.CERAMIC ECUE1E102KBQ
C164 4030013850 S.CERAMIC ECUE1E102KBQ
C165 4030014020 S.CERAMIC ECUE1H020BCQ
C166 4030013850 S.CERAMIC ECUE1E102KBQ
C167 4030013850 S.CERAMIC ECUE1E102KBQ
C168 4030013850 S.CERAMIC ECUE1E102KBQ
C169 4030013850 S.CERAMIC ECUE1E102KBQ
C170 4030013850 S.CERAMIC ECUE1E102KBQ
C171 4030013850 S.CERAMIC ECUE1E102KBQ
C172 4030013850 S.CERAMIC ECUE1E102KBQ
C173 4030013850 S.CERAMIC ECUE1E102KBQ
C178 4030013850 S.CERAMIC ECUE1E102KBQ
C180 4030013850 S.CERAMIC ECUE1E102KBQ
C182 4030013850 S.CERAMIC ECUE1E102KBQ
C183 4030014000 S.CERAMIC ECUE1H1R5BCQ
C186 4030013850 S.CERAMIC ECUE1E102KBQ
C188 4030013850 S.CERAMIC ECUE1E102KBQ
C190 4030014000 S.CERAMIC ECUE1H1R5BCQ
C191 4030014020 S.CERAMIC ECUE1H020BCQ
C192 4030014070 S.CERAMIC ECUE1H040BCQ
C193 4030014110 S.CERAMIC ECUE1H080CCQ
C194 4030014150 S.CERAMIC ECUE1H220JCQ
C195 4030014000 S.CERAMIC ECUE1H1R5BCQ
C196 4030014020 S.CERAMIC ECUE1H020BCQ
C197 4030014060 S.CERAMIC ECUE1H3R5BCQ
C198 4030014090 S.CERAMIC ECUE1H060CCQ
C199 4030014130 S.CERAMIC ECUE1H120JCQ
C200 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C206 4030014060 S.CERAMIC ECUE1H3R5BCQ
C207 4030014170 S.CERAMIC ECUE1H330JCQ
C208 4030014180 S.CERAMIC ECUE1H470JCQ
C209 4030013850 S.CERAMIC ECUE1E102KBQ
C210 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C211 4030013850 S.CERAMIC ECUE1E102KBQ
C214 4030013850 S.CERAMIC ECUE1E102KBQ
C216 4030014130 S.CERAMIC ECUE1H120JCQ
C218 4030013980 S.CERAMIC ECUE1H010BCQ
C233 4030013850 S.CERAMIC ECUE1E102KBQ
C234 4030013850 S.CERAMIC ECUE1E102KBQ
C235 4030013850 S.CERAMIC ECUE1E102KBQ
C236 4030013850 S.CERAMIC ECUE1E102KBQ
C237 4030014000 S.CERAMIC ECUE1H1R5BCQ
C239 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C241 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C242 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C243 4030014240 S.CERAMIC ECUE1H180JCQ
C244 4030014080 S.CERAMIC ECUE1H050BCQ
C247 4030014090 S.CERAMIC ECUE1H060CCQ
C248 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C249 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C250 4030014110 S.CERAMIC ECUE1H080CCQ
C251 4030014070 S.CERAMIC ECUE1H040BCQ
C252 4030014110 S.CERAMIC ECUE1H080CCQ
C256 4030013850 S.CERAMIC ECUE1E102KBQ
C257 4030013850 S.CERAMIC ECUE1E102KBQ
C258 4030013850 S.CERAMIC ECUE1E102KBQ
C259 4030014200 S.CERAMIC ECUE1H101JCQ
C264 4030013850 S.CERAMIC ECUE1E102KBQ
C402 4030014180 S.CERAMIC ECUE1H470JCQ
C410 4030013850 S.CERAMIC ECUE1E102KBQ
C414 4030013850 S.CERAMIC ECUE1E102KBQ
C416 4030014160 S.CERAMIC ECUE1H270JCQ
C423 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C424 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C427 4030014350 S.CERAMIC ECUE1H560JCQ
C429 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C430 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C431 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C432 4030013850 S.CERAMIC ECUE1E102KBQ
C433 4030013850 S.CERAMIC ECUE1E102KBQ
C434 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C435 4030013850 S.CERAMIC ECUE1E102KBQ
C436 4030014070 S.CERAMIC ECUE1H040BCQ
C503 4030013850 S.CERAMIC ECUE1E102KBQ
C504 4030013850 S.CERAMIC ECUE1E102KBQ
C505 4030013850 S.CERAMIC ECUE1E102KBQ
C507 4030014210 S.CERAMIC ECUE1H151JCQ
C510 4030014020 S.CERAMIC ECUE1H020BCQ
C511 4030014170 S.CERAMIC ECUE1H330JCQ
C512 4030014130 S.CERAMIC ECUE1H120JCQ
C513 4030014440 S.CERAMIC ECUE1H820JCQ
C514 4030014210 S.CERAMIC ECUE1H151JCQ
C515 4030014200 S.CERAMIC ECUE1H101JCQ
C516 4030014330 S.CERAMIC ECUE1H221JCQ
C517 4030014320 S.CERAMIC ECUE1H181JCQ
C518 4030009810 S.CERAMIC C1005 JB 1E 102K-T-A
C519 4030013890 S.CERAMIC C1005 JB 1H 152K-T-N
C520 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C521 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C522 4030013880 S.CERAMIC C1005 JB 1H 222K-T-N
C523 4030013890 S.CERAMIC C1005 JB 1H 152K-T-N
C524 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C525 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C526 4030013950 S.CERAMIC C1005 JB 1A 393K-T-N
C527 4030014440 S.CERAMIC ECUE1H820JCQ
C528 4030014160 S.CERAMIC ECUE1H270JCQ
C529 4030014210 S.CERAMIC ECUE1H151JCQ
C530 4030014490 S.CERAMIC ECUE1E331KBQ
C531 4030014320 S.CERAMIC ECUE1H181JCQ
C532 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C533 4030013890 S.CERAMIC C1005 JB 1H 152K-T-N
C534 4030014490 S.CERAMIC ECUE1E331KBQ
C535 4030013850 S.CERAMIC ECUE1E102KBQ
C536 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C537 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C538 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C539 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C540 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C541 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C542 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C543 4030013850 S.CERAMIC ECUE1E102KBQ
C544 4030013850 S.CERAMIC ECUE1E102KBQ
C545 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C546 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C548 4030013850 S.CERAMIC ECUE1E102KBQ
C550 4030014110 S.CERAMIC ECUE1H080CCQ
C553 4030013850 S.CERAMIC ECUE1E102KBQ
C557 4030013850 S.CERAMIC ECUE1E102KBQ
C558 4030013850 S.CERAMIC ECUE1E102KBQ
C560 4030013850 S.CERAMIC ECUE1E102KBQ
C561 4030013850 S.CERAMIC ECUE1E102KBQ
C562 4030013850 S.CERAMIC ECUE1E102KBQ
C563 4030013850 S.CERAMIC ECUE1E102KBQ
C654 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C655 4550000510 S.TANTALUM TESVA 1V 473M1-8L
C656 4030014110 S.CERAMIC ECUE1H080CCQ
C657 4030014230 S.CERAMIC ECUE1E681KBQ
C658 4030013880 S.CERAMIC C1005 JB 1H 222K-T-N
C659 4550006200 S.TANTALUM ECST0JY106R
C662 4030013850 S.CERAMIC ECUE1E102KBQ
C663 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C664 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
