Icom IC-R3 Service Manual

S.=Surface mount
L55 6200005650 S.COIL ELJRE 8N2Z-F
L57 6200005710 S.COIL ELJRE 27NG-F
L58 6200005730 S.COIL ELJRE 39NG-F
L59 6200005720 S.COIL ELJRE 33NG-F
L60 6200007230 S.COIL LQN21A 15NJ04
L61 6200007700 S.COIL LQN21A 22NJ04
L76 6200004920 S.COIL MLF1608A 2R2K-T
L77 6200004730 S.COIL MLF1608A 1R2K-T
L78 6200007170 S.COIL MLF1608A 3R3K-T
L81 6200004940 S.COIL MLF1608D R27K-T
L82 6200005140 S.COIL MLF1608D R33K-T
L83 6200004790 S.COIL MLF1608D R47K-T
L84 6200004790 S.COIL MLF1608D R47K-T
L85 6200006970 S.COIL MLF1608A 3R9K-T
L86 6200006970 S.COIL MLF1608A 3R9K-T
L87 6200004790 S.COIL MLF1608D R47K-T
L88 6200003630 S.COIL MLF1608D R68K-T
L89 6200007170 S.COIL MLF1608A 3R3K-T
L90 6200007170 S.COIL MLF1608A 3R3K-T
L91 6200002040 S.COIL NL 252018T-101J
L121 6200007170 S.COIL MLF1608A 3R3K-T
L122 6200007170 S.COIL MLF1608A 3R3K-T
L801 6200005620 S.COIL ELJRE 4N7Z-F
L802 6200005640 S.COIL ELJRE 6N8Z-F
L803 6200007770 S.COIL LQN21A R10J04
L804 6200005660 S.COIL ELJRE 10NG-F
L805 6200005620 S.COIL ELJRE 4N7Z-F
L806 6200005650 S.COIL ELJRE 8N2Z-F
L807 6200005670 S.COIL ELJRE 12NG-F
L851 6200005600 S.COIL ELJRE 3N3Z-F
L852 6200005620 S.COIL ELJRE 4N7Z-F
L853 6200007770 S.COIL LQN21A R10J04
L854 6200005630 S.COIL ELJRE 5N6Z-F
L855 6200005600 S.COIL ELJRE 3N3Z-F
L901 6200003270 S.COIL NL 252018T-R56J
L902 6150005070 S.COIL LS-534 (4KMH)
L903 6200005030 S.COIL NL 252018T-180J
L906 6200005720 S.COIL ELJRE 33NG-F
L907 6200005020 S.COIL NL 252018T-150J
L908 6200007770 S.COIL LQN21A R10J04
L909 6200007770 S.COIL LQN21A R10J04
L911 6200005640 S.COIL ELJRE 6N8Z-F
L912 6200005650 S.COIL ELJRE 8N2Z-F
L914 6200005670 S.COIL ELJRE 12NG-F
L922 6200005660 S.COIL ELJRE 10NG-F
R1 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R2 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R3 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
R4 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R5 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R6 7510001190 S.THERMISTOR NTCCM1608 4BH 472KC
R7 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R8 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R11 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R12 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R13 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R14 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R15 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R16 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R17 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R18 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R27 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R28 7030007060 S.RESISTOR ERJ2GEJ 684X (680 kΩ)
R29 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R30 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R31 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R34 7030005590 S.RESISTOR ERJ2GEJ 680 X (68 Ω)
R35 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ)
R36 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R37 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R50 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
[OTH-2] only
R52 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R53 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R54 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R55 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R56 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R57 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R58 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
R59 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
R60 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R61 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R62 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R64 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R71 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R72 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R73 7030008370 S.RESISTOR ERJ2GEJ 561 X (560 Ω)
R74 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R75 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R76 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R77 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R78 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R81 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R82 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R83 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R84 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R85 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R86 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R101 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R102 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R103 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R104 7510001150 S.THERMISTOR NTCCM1608 4BH 103KC
R105 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R107 7030007250 S.RESISTOR ERJ2GEJ 220 X (22 Ω)
R108 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R109 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R110 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R111 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R112 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R113 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R114 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R115 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ)
R116 7030005590 S.RESISTOR ERJ2GEJ 680 X (68 Ω)
R117 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R118 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R119 7030009200 S.RESISTOR ERJ2GEJ 390 X (39 Ω)
R121 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R122 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R123 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R124 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R125 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R128 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R129 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R130 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R131 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R132 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R133 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R134 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R135 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω)
R137 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R138 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R139 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R140 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R169 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R177 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R178 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R179 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R200 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R201 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R202 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R203 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R204 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R205 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R222 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R223 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R224 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R225 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R226 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R227 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R228 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R229 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R230 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R231 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R241 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R255 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R256 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R257 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R800 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ)
R801 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R802 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R804 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R805 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
