Icom IC-R3 Service Manual

S.=Surface mount
R806 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R807 7030007250 S.RESISTOR ERJ2GEJ 220 X (22 Ω)
R808 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R809 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R810 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R850 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ)
R851 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R852 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R854 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R855 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R857 7030007250 S.RESISTOR ERJ2GEJ 220 X (22 Ω)
R858 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R859 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R860 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R861 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R862 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R863 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R864 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R865 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R875 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R876 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
R877 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R878 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R901 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R903 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ)
R904 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ)
R905 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R906 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R907 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ)
R908 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ)
R909 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R910 7030005590 S.RESISTOR ERJ2GEJ 680 X (68 Ω)
R912 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R914 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R917 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R918 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R922 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R923 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R924 7030007250 S.RESISTOR ERJ2GEJ 220 X (22 Ω)
R925 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R926 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R927 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R928 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R929 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R930 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R931 7030008290 S.RESISTOR ERJ2GEJ 183 X (18 kΩ)
R932 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R933 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R934 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R935 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R936 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R937 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R938 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R939 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R940 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R941 7030005570 S.RESISTOR ERJ2GEJ 820 X (82 Ω)
R942 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R943 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R944 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R945 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R946 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R947 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R948 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R950 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω)
R957 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R958 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ)
[OTH], [OTH-1] only
R959 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R960 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R961 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R962 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R963 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ)
R965 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R969 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R972 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R973 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R974 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C3 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030013850 S.CERAMIC ECUE1E102KBQ
C6 4030013850 S.CERAMIC ECUE1E102KBQ
C7 4030013850 S.CERAMIC ECUE1E102KBQ
C8 4030013850 S.CERAMIC ECUE1E102KBQ
C9 4030013850 S.CERAMIC ECUE1E102KBQ
C10 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C11 4030013850 S.CERAMIC ECUE1E102KBQ
C12 4030013980 S.CERAMIC ECUE1H010BCQ
C13 4030014140 S.CERAMIC ECUE1H150JCQ
C14 4030014020 S.CERAMIC ECUE1H020BCQ
C15 4030014240 S.CERAMIC ECUE1H180JCQ
C16 4030013980 S.CERAMIC ECUE1H010BCQ
C17 4030014120 S.CERAMIC ECUE1H100CCQ
C19 4030014240 S.CERAMIC ECUE1H180JCQ
C20 4030014240 S.CERAMIC ECUE1H180JCQ
C21 4030014240 S.CERAMIC ECUE1H180JCQ
C22 4030014070 S.CERAMIC ECUE1H040BCQ
C23 4030014060 S.CERAMIC ECUE1H3R5BCQ
C24 4030014290 S.CERAMIC ECUE1H090CCQ
C25 4030013980 S.CERAMIC ECUE1H010BCQ
C26 4030014090 S.CERAMIC ECUE1H060CCQ
C27 4030014050 S.CERAMIC ECUE1H030BCQ
C28 4030013850 S.CERAMIC ECUE1E102KBQ
C30 4030013850 S.CERAMIC ECUE1E102KBQ
C31 4030013850 S.CERAMIC ECUE1E102KBQ
C32 4030013850 S.CERAMIC ECUE1E102KBQ
C33 4030013850 S.CERAMIC ECUE1E102KBQ
C35 4030013980 S.CERAMIC ECUE1H010BCQ
C36 4030013850 S.CERAMIC ECUE1E102KBQ
C37 4030013850 S.CERAMIC ECUE1E102KBQ
C38 4030013850 S.CERAMIC ECUE1E102KBQ
C39 4030013850 S.CERAMIC ECUE1E102KBQ
C40 4030014130 S.CERAMIC ECUE1H120JCQ
C41 4030014030 S.CERAMIC ECUE1H2R5BCQ
C42 4030014090 S.CERAMIC ECUE1H060CCQ
C43 4030014180 S.CERAMIC ECUE1H470JCQ
C44 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C45 4030014050 S.CERAMIC ECUE1H030BCQ
C46 4030014090 S.CERAMIC ECUE1H060CCQ
C47 4030014050 S.CERAMIC ECUE1H030BCQ
C48 4030014090 S.CERAMIC ECUE1H060CCQ
C49 4030014050 S.CERAMIC ECUE1H030BCQ
C51 4030013980 S.CERAMIC ECUE1H010BCQ
C52 4030013980 S.CERAMIC ECUE1H010BCQ
C53 4030013850 S.CERAMIC ECUE1E102KBQ
C54 4030014020 S.CERAMIC ECUE1H020BCQ
C55 4030014200 S.CERAMIC ECUE1H101JCQ
C56 4030014050 S.CERAMIC ECUE1H030BCQ
C57 4030014200 S.CERAMIC ECUE1H101JCQ
C58 4030013850 S.CERAMIC ECUE1E102KBQ
C59 4030013850 S.CERAMIC ECUE1E102KBQ
C60 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C61 4030013850 S.CERAMIC ECUE1E102KBQ
C62 4030013850 S.CERAMIC ECUE1E102KBQ
C63 4030013850 S.CERAMIC ECUE1E102KBQ
C64 4030014140 S.CERAMIC ECUE1H150JCQ
C65 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C66 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C67 4030013850 S.CERAMIC ECUE1E102KBQ
C68 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C69 4550006950 S.TANTALUM ECST0JX476R
C70 4030013850 S.CERAMIC ECUE1E102KBQ
C71 4030013850 S.CERAMIC ECUE1E102KBQ
C74 4030013850 S.CERAMIC ECUE1E102KBQ
C81 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C82 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C87 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C88 4030014200 S.CERAMIC ECUE1H101JCQ
C90 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C91 4030014240 S.CERAMIC ECUE1H180JCQ
C92 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C93 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C94 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C95 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C96 4030013850 S.CERAMIC ECUE1E102KBQ
C97 4030013850 S.CERAMIC ECUE1E102KBQ
C98 4030013850 S.CERAMIC ECUE1E102KBQ
C99 4030013850 S.CERAMIC ECUE1E102KBQ
C101 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C102 4550006200 S.TANTALUM ECST0JY106R
C103 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C104 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
6 - 3
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
