Icom IC-R3 Service Manual

S.=Surface mount
C105 4030014200 S.CERAMIC ECUE1H101JCQ
C106 4030014120 S.CERAMIC ECUE1H100CCQ
C107 4030013850 S.CERAMIC ECUE1E102KBQ
C108 4030014220 S.CERAMIC ECUE1E471KBQ
C109 4030014220 S.CERAMIC ECUE1E471KBQ
C110 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C111 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C112 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C113 4030013850 S.CERAMIC ECUE1E102KBQ
C114 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C115 4030013850 S.CERAMIC ECUE1E102KBQ
C116 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C117 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C118 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C121 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C122 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C123 4030014130 S.CERAMIC ECUE1H120JCQ
C124 4030014130 S.CERAMIC ECUE1H120JCQ
C125 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C126 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C141 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C142 4030014100 S.CERAMIC ECUE1H070CCQ
C143 4030013850 S.CERAMIC ECUE1E102KBQ
C150 4030013850 S.CERAMIC ECUE1E102KBQ
C151 4030013850 S.CERAMIC ECUE1E102KBQ
C152 4030013850 S.CERAMIC ECUE1E102KBQ
C153 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C167 4030013850 S.CERAMIC ECUE1E102KBQ
C168 4030013850 S.CERAMIC ECUE1E102KBQ
C169 4030013850 S.CERAMIC ECUE1E102KBQ
C170 4030013850 S.CERAMIC ECUE1E102KBQ
C171 4030013850 S.CERAMIC ECUE1E102KBQ
C172 4030013850 S.CERAMIC ECUE1E102KBQ
C173 4510007130
S.ELECTROLYTIC EEFCD 0J 470R
C174 4030013850 S.CERAMIC ECUE1E102KBQ
C175 4030013850 S.CERAMIC ECUE1E102KBQ
C176 4030014180 S.CERAMIC ECUE1H470JCQ
C177 4030014180 S.CERAMIC ECUE1H470JCQ
C186 4030013850 S.CERAMIC ECUE1E102KBQ
C187 4030014020 S.CERAMIC ECUE1H020BCQ
C188 4030013850 S.CERAMIC ECUE1E102KBQ
C189 4030014020 S.CERAMIC ECUE1H020BCQ
C190 4030014050 S.CERAMIC ECUE1H030BCQ
C191 4030014080 S.CERAMIC ECUE1H050BCQ
C192 4030014150 S.CERAMIC ECUE1H220JCQ
C193 4030014150 S.CERAMIC ECUE1H220JCQ
C194 4030014170 S.CERAMIC ECUE1H330JCQ
C195 4030014050 S.CERAMIC ECUE1H030BCQ
C196 4030014030 S.CERAMIC ECUE1H2R5BCQ
C197 4030014080 S.CERAMIC ECUE1H050BCQ
C198 4030014130 S.CERAMIC ECUE1H120JCQ
C199 4030014340 S.CERAMIC ECUE1H390JCQ
C200 4550006680 S.TANTALUM ECST0JY156R
C201 4030013850 S.CERAMIC ECUE1E102KBQ
C202 4030013850 S.CERAMIC ECUE1E102KBQ
C203 4030013850 S.CERAMIC ECUE1E102KBQ
C211 4030014080 S.CERAMIC ECUE1H050BCQ
C212 4030014020 S.CERAMIC ECUE1H020BCQ
C213 4030014080 S.CERAMIC ECUE1H050BCQ
C214 4030014030 S.CERAMIC ECUE1H2R5BCQ
C215 4030014000 S.CERAMIC ECUE1H1R5BCQ
C216 4030014030 S.CERAMIC ECUE1H2R5BCQ
C234 4030013850 S.CERAMIC ECUE1E102KBQ
C244 4030013850 S.CERAMIC ECUE1E102KBQ
C261 4030014180 S.CERAMIC ECUE1H470JCQ
C262 4030013850 S.CERAMIC ECUE1E102KBQ
C273 4030013850 S.CERAMIC ECUE1E102KBQ
C274 4030013850 S.CERAMIC ECUE1E102KBQ
C302 4030014320 S.CERAMIC ECUE1H181JCQ
C303 4030013850 S.CERAMIC ECUE1E102KBQ
C304 4030013850 S.CERAMIC ECUE1E102KBQ
C305 4030014000 S.CERAMIC ECUE1H1R5BCQ
C307 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C321 4030014170 S.CERAMIC ECUE1H330JCQ
C322 4030014130 S.CERAMIC ECUE1H120JCQ
C323 4030014440 S.CERAMIC ECUE1H820JCQ
C324 4030014210 S.CERAMIC ECUE1H151JCQ
C325 4030014200 S.CERAMIC ECUE1H101JCQ
C326 4030014330 S.CERAMIC ECUE1H221JCQ
C327 4030014320 S.CERAMIC ECUE1H181JCQ
C328 4030013850 S.CERAMIC ECUE1E102KBQ
C329 4030016900 S.CERAMIC ECUE1H152KBQ
C330 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C331 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C332 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C333 4030016900 S.CERAMIC ECUE1H152KBQ
C334 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C335 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C336 4030016940 S.CERAMIC ECJ0EB1A393K
C337 4030014440 S.CERAMIC ECUE1H820JCQ
C338 4030014160 S.CERAMIC ECUE1H270JCQ
C339 4030014210 S.CERAMIC ECUE1H151JCQ
C340 4030014490 S.CERAMIC ECUE1E331KBQ
C341 4030014320 S.CERAMIC ECUE1H181JCQ
C342 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C344 4030014490 S.CERAMIC ECUE1E331KBQ
C345 4030013850 S.CERAMIC ECUE1E102KBQ
C346 4030014230 S.CERAMIC ECUE1E681KBQ
C347 4030013880 S.CERAMIC C1005 JB 1H 222K-T-N
C348 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C349 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C350 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C351 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C363 4030013850 S.CERAMIC ECUE1E102KBQ
C366 4030013850 S.CERAMIC ECUE1E102KBQ
C371 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C372 4030013850 S.CERAMIC ECUE1E102KBQ
C373 4030013850 S.CERAMIC ECUE1E102KBQ
C374 4030013850 S.CERAMIC ECUE1E102KBQ
C375 4030013850 S.CERAMIC ECUE1E102KBQ
C381 4030013850 S.CERAMIC ECUE1E102KBQ
C389 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C395 4030014180 S.CERAMIC ECUE1H470JCQ
C396 4030014340 S.CERAMIC ECUE1H390JCQ
C400 4030014020 S.CERAMIC ECUE1H020BCQ
C401 4030013850 S.CERAMIC ECUE1E102KBQ
C801 4030013850 S.CERAMIC ECUE1E102KBQ
C802 4030014140 S.CERAMIC ECUE1H150JCQ
C803 4030013850 S.CERAMIC ECUE1E102KBQ
C804 4030013850 S.CERAMIC ECUE1E102KBQ
C805 4030013850 S.CERAMIC ECUE1E102KBQ
C806 4030013850 S.CERAMIC ECUE1E102KBQ
C807 4030013850 S.CERAMIC ECUE1E102KBQ
C808 4030013850 S.CERAMIC ECUE1E102KBQ
C809 4030014140 S.CERAMIC ECUE1H150JCQ
C810 4030013850 S.CERAMIC ECUE1E102KBQ
C811 4030013850 S.CERAMIC ECUE1E102KBQ
C812 4030014050 S.CERAMIC ECUE1H030BCQ
C813 4030013980 S.CERAMIC ECUE1H010BCQ
C814 4030014080 S.CERAMIC ECUE1H050BCQ
C815 4030014280 S.CERAMIC ECUE1H0R3BCQ
C816 4030014050 S.CERAMIC ECUE1H030BCQ
C817 4030013850 S.CERAMIC ECUE1E102KBQ
C818 4030014320 S.CERAMIC ECUE1H181JCQ
C851 4030013850 S.CERAMIC ECUE1E102KBQ
C852 4030014120 S.CERAMIC ECUE1H100CCQ
C853 4030014110 S.CERAMIC ECUE1H080CCQ
C854 4030013850 S.CERAMIC ECUE1E102KBQ
C855 4030013850 S.CERAMIC ECUE1E102KBQ
C856 4030013850 S.CERAMIC ECUE1E102KBQ
C857 4030013850 S.CERAMIC ECUE1E102KBQ
C858 4030013850 S.CERAMIC ECUE1E102KBQ
C859 4030014120 S.CERAMIC ECUE1H100CCQ
C860 4030013850 S.CERAMIC ECUE1E102KBQ
C861 4030013850 S.CERAMIC ECUE1E102KBQ
C900 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C901 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C902 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C903 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C904 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C905 4030014440 S.CERAMIC ECUE1H820JCQ
C906 4030014340 S.CERAMIC ECUE1H390JCQ
C907 4030014190 S.CERAMIC ECUE1H680JCQ
C908 4550006140 S.TANTALUM ECST1EY474R
C909 4550006200 S.TANTALUM ECST0JY106R
C910 4030014220 S.CERAMIC ECUE1E471KBQ
C911 4550006140 S.TANTALUM ECST1EY474R
C912 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C913 4030013850 S.CERAMIC ECUE1E102KBQ
C914 4030013850 S.CERAMIC ECUE1E102KBQ
C915 4030013850 S.CERAMIC ECUE1E102KBQ
C916 4030013850 S.CERAMIC ECUE1E102KBQ
C917 4030017020 S.CERAMIC JMK212BJ475MG-T
C918 4030017020 S.CERAMIC JMK212BJ475MG-T
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
