Icom IC-R3 Service Manual

S.=Surface mount
C919 4030017020 S.CERAMIC JMK212BJ475MG-T
C920 4550006200 S.TANTALUM ECST0JY106R
C921 4030013850 S.CERAMIC ECUE1E102KBQ
C922 4550006960 S.TANTALUM TEMSVB2 0G 107M8R
C923 4030017020 S.CERAMIC JMK212BJ475MG-T
C924 4550006970 S.TANTALUM TEMSVA 0G 476M8R
C925 4550006970 S.TANTALUM TEMSVA 0G 476M8R
C926 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C927 4030014500 S.CERAMIC ECUE1H121JCQ
C928 4030013850 S.CERAMIC ECUE1E102KBQ
C929 4030014500 S.CERAMIC ECUE1H121JCQ
C930 4030014110 S.CERAMIC ECUE1H080CCQ
C931 4030014110 S.CERAMIC ECUE1H080CCQ
C932 4030014020 S.CERAMIC ECUE1H020BCQ
C933 4030014140 S.CERAMIC ECUE1H150JCQ
C934 4030014000 S.CERAMIC ECUE1H1R5BCQ
C935 4030014070 S.CERAMIC ECUE1H040BCQ
C936 4030014020 S.CERAMIC ECUE1H020BCQ
C937 4030017020 S.CERAMIC JMK212BJ475MG-T
C938 4030017020 S.CERAMIC JMK212BJ475MG-T
C939 4030013850 S.CERAMIC ECUE1E102KBQ
C941 4030013850 S.CERAMIC ECUE1E102KBQ
C942 4030014320 S.CERAMIC ECUE1H181JCQ
C943 4030013850 S.CERAMIC ECUE1E102KBQ
C944 4030014220 S.CERAMIC ECUE1E471KBQ
C945 4030014220 S.CERAMIC ECUE1E471KBQ
C946 4030013850 S.CERAMIC ECUE1E102KBQ
C947 4030013850 S.CERAMIC ECUE1E102KBQ
C950 4030013850 S.CERAMIC ECUE1E102KBQ
C951 4030013850 S.CERAMIC ECUE1E102KBQ
C952 4030014220 S.CERAMIC ECUE1E471KBQ
C953 4030014000 S.CERAMIC ECUE1H1R5BCQ
C954 4550006200 S.TANTALUM ECST0JY106R
C955 4030014220 S.CERAMIC ECUE1E471KBQ
C956 4550006680 S.TANTALUM ECST0JY156R
C957 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C958 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C959 4030013850 S.CERAMIC ECUE1E102KBQ
C960 4030014220 S.CERAMIC ECUE1E471KBQ
C961 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C962 4550006760 S.TANTALUM TEMSVB2 1A 336M-8R
C963 4030014000 S.CERAMIC ECUE1H1R5BCQ
C964 4030014050 S.CERAMIC ECUE1H030BCQ
C977 4030014220 S.CERAMIC ECUE1E471KBQ
C978 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C979 4030013850 S.CERAMIC ECUE1E102KBQ
C982 4030013850 S.CERAMIC ECUE1E102KBQ
C983 4030013850 S.CERAMIC ECUE1E102KBQ
C984 4030013850 S.CERAMIC ECUE1E102KBQ
C985 4030013850 S.CERAMIC ECUE1E102KBQ
C988 4030013850 S.CERAMIC ECUE1E102KBQ
C990 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C992 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C993 4030013850 S.CERAMIC ECUE1E102KBQ
C994 4030013850 S.CERAMIC ECUE1E102KBQ
J1 6510022160 S.CONNECTOR AXN440C040P
J2 6450001690 CONNECTOR HSJ1456-01-220
J3 6450001690 CONNECTOR HSJ1456-01-220
J4 6450002130 CONNECTOR 04-730A1-02BKA
J5 6510022380 S.CONNECTOR IMSA-9261B-04Y913 [OTH-2] only
J6 6510022320 CONNECTOR IMSA-9230B-1-03Z112-T
[OTH-2] only
J7 6510022320 CONNECTOR IMSA-9230B-1-03Z112-T
[OTH-2] only
S1 2250000390 ENCODER TP90N00E20-16F-1995
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
EP1 6910012350 S.BEAD MMZ1608Y 102BT
EP2 6910012350 S.BEAD MMZ1608Y 102BT
EP3 0910053014 PCB B 5370D
Q401 1580000730 S.FET 3SK293 (TE85L)
Q501 1580000730 S.FET 3SK293 (TE85L)
Q601 1580000730 S.FET 3SK293 (TE85L)
Q701 1580000730 S.FET 3SK293 (TE85L)
D401 1720000660 S.VARICAP 1SV288 (TPH2)
D402 1720000660 S.VARICAP 1SV288 (TPH2)
D403 1790001260 S.DIODE MA2S077-(TX)
D404 1790001260 S.DIODE MA2S077-(TX)
D501 1720000660 S.VARICAP 1SV288 (TPH2)
D502 1720000660 S.VARICAP 1SV288 (TPH2)
D503 1790001260 S.DIODE MA2S077-(TX)
D504 1790001260 S.DIODE MA2S077-(TX)
D601 1720000650 S.VARICAP 1SV286 (TPH3)
D602 1720000650 S.VARICAP 1SV286 (TPH3)
D603 1790001260 S.DIODE MA2S077-(TX)
D604 1790001260 S.DIODE MA2S077-(TX)
D701 1720000650 S.VARICAP 1SV286 (TPH3)
D702 1720000650 S.VARICAP 1SV286 (TPH3)
D703 1790001260 S.DIODE MA2S077-(TX)
D704 1790001260 S.DIODE MA2S077-(TX)
L401 6200008550 S.COIL ELJND R56J 0.56U
L402 6200008550 S.COIL ELJND R56J 0.56U
L403 6200007120 S.COIL ELJND 1R0J 1U
L404 6200008550 S.COIL ELJND R56J 0.56U
L405 6200008550 S.COIL ELJND R56J 0.56U
L501 6200007290 S.COIL ELJND 56NJF
L502 6200007790 S.COIL LQN21A R15J04
L503 6200007120 S.COIL ELJND 1R0J 1U
L504 6200007790 S.COIL LQN21A R15J04
L505 6200007290 S.COIL ELJND 56NJF
L601 6200007270 S.COIL ELJND 33NJF
L602 6200007770 S.COIL LQN21A R10J04
L603 6200007120 S.COIL ELJND 1R0J 1U
L604 6200007760 S.COIL LQN21A 82NJ04
L605 6200007270 S.COIL ELJND 33NJF
L701 6200007070 S.COIL ELJND 15NKF
L702 6200007740 S.COIL LQN21A 47NJ04
L703 6200007120 S.COIL ELJND 1R0J 1U
L704 6200007740 S.COIL LQN21A 47NJ04
L705 6200007070 S.COIL ELJND 15NKF
R401 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R402 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R403 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R404 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R405 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R407 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R408 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R409 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R410 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R501 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R502 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R503 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R504 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R505 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R507 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R508 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R509 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R510 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R601 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R602 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R603 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R604 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R605 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R606 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω)
R607 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R608 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R609 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R610 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R611 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R701 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R702 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R703 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R704 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R705 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R707 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R708 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF-B UNIT]
