Icom IC-R3

S.=Surface mount
R709 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R710 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R711 7030007250 S.RESISTOR ERJ2GEJ 220 X (22 Ω)
C401 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C402 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C403 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C404 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C405 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C406 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C407 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C408 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C409 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C410 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C411 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C501 4030013850 S.CERAMIC ECUE1E102KBQ
C502 4030013850 S.CERAMIC ECUE1E102KBQ
C503 4030013850 S.CERAMIC ECUE1E102KBQ
C504 4030013850 S.CERAMIC ECUE1E102KBQ
C505 4030013850 S.CERAMIC ECUE1E102KBQ
C506 4030013850 S.CERAMIC ECUE1E102KBQ
C507 4030013850 S.CERAMIC ECUE1E102KBQ
C508 4030013850 S.CERAMIC ECUE1E102KBQ
C509 4030013850 S.CERAMIC ECUE1E102KBQ
C510 4030013850 S.CERAMIC ECUE1E102KBQ
C511 4030013850 S.CERAMIC ECUE1E102KBQ
C601 4030013850 S.CERAMIC ECUE1E102KBQ
C602 4030013850 S.CERAMIC ECUE1E102KBQ
C603 4030014120 S.CERAMIC ECUE1H100CCQ
C604 4030013850 S.CERAMIC ECUE1E102KBQ
C605 4030013850 S.CERAMIC ECUE1E102KBQ
C606 4030013850 S.CERAMIC ECUE1E102KBQ
C607 4030013850 S.CERAMIC ECUE1E102KBQ
C608 4030014050 S.CERAMIC ECUE1H030BCQ
C609 4030013850 S.CERAMIC ECUE1E102KBQ
C610 4030013850 S.CERAMIC ECUE1E102KBQ
C611 4030013850 S.CERAMIC ECUE1E102KBQ
C701 4030013850 S.CERAMIC ECUE1E102KBQ
C702 4030013850 S.CERAMIC ECUE1E102KBQ
C703 4030013850 S.CERAMIC ECUE1E102KBQ
C704 4030013850 S.CERAMIC ECUE1E102KBQ
C705 4030013850 S.CERAMIC ECUE1E102KBQ
C706 4030013850 S.CERAMIC ECUE1E102KBQ
C707 4030013850 S.CERAMIC ECUE1E102KBQ
C708 4030013850 S.CERAMIC ECUE1E102KBQ
C709 4030013850 S.CERAMIC ECUE1E102KBQ
C710 4030013850 S.CERAMIC ECUE1E102KBQ
C711 4030013850 S.CERAMIC ECUE1E102KBQ
J3 6510022330 CONNECTOR IMSA-9230B-1-04Z113-T
J4 6510022340 CONNECTOR IMSA-9230B-1-06Z113-T
EP1 0910053034 PCB B 5372D
IC2 1140008440 S.IC AK93C10AF-E2
IC3 1180001820 S.IC XC62FP3002MR
IC5 1110005070 S.IC S-80925ALMP-DAN-T2
IC9 1110003800 S.IC NJM2904V-TE1
IC10 1110004790 S.IC XC6371A351PR
IC11 1140008990 S.IC M38267M8L-256GP RX-2304
IC14 1110004520 S.IC M5222FP 600C
IC15 1190000710 S.IC TA31056F (TP1)
IC801 1190001250 S.IC MB3776APFV-G-BND-ER
IC901 1190001110 S.IC LV4127W
IC902 1190001130 S.IC M35017-001FP
IC903 1130006540 S.IC TC7S02FU (TE85R)
Q1 1590001180 S.TRANSISTOR XP1210 (TX)
Q2 1590001440 S.TRANSISTOR UN9214 (TX)
Q4 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q5 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q6 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q7 1590001440 S.TRANSISTOR UN9214 (TX)
Q8 1590002430 S.TRANSISTOR DTA144EE TL
Q11 1590001440 S.TRANSISTOR UN9214 (TX)
Q17 1590001390 S.FET 2SJ144-Y (TE85R)
Q18 1590002430 S.TRANSISTOR DTA144EE TL
Q19 1590001940 S.TRANSISTOR DTC144EE TL
Q23 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q26 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q30 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q31 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q36 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q37 1590001390 S.FET 2SJ144-Y (TE85R)
Q38 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q39 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q40 1590002430 S.TRANSISTOR DTA144EE TL
Q41 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q42 1590001650 S.TRANSISTOR XP4601 (TX)
Q43 1560000840 S.FET 2SK1829 (TE85R)
Q44 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q50 1590001440 S.TRANSISTOR UN9214 (TX)
Q51 1590002430 S.TRANSISTOR DTA144EE TL
Q201 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q202 1590001440 S.TRANSISTOR UN9214 (TX)
Q203 1590002950 S.FET HAT1023R-EL
Q303 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q304 1530003190 S.TRANSISTOR 2SC4617 TLQ
Q801 1560001110 S.FET 2SK2493 (TE16L)
Q802 1590002820 S.TRANSISTOR UMY1N TR
Q804 1560001110 S.FET 2SK2493 (TE16L)
Q806 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q820 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q821 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q902 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q903 1510000620 S.TRANSISTOR 2SA1576 T107 S
Q904 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q908 1590001440 S.TRANSISTOR UN9214 (TX)
D1 1790001250 S.DIODE MA2S111-(TX)
D2 1790001250 S.DIODE MA2S111-(TX)
D3 1790001560 S.DIODE 1SS372 (TE85R)
D4 1790000970 S.DIODE MA729 (TX)
D5 1790001560 S.DIODE 1SS372 (TE85R)
D7 1790001250 S.DIODE MA2S111-(TX)
D8 1790001250 S.DIODE MA2S111-(TX)
D9 1790001250 S.DIODE MA2S111-(TX)
D14 1790001250 S.DIODE MA2S111-(TX)
D15 1790001560 S.DIODE 1SS372 (TE85R)
D16 1790000850 S.DIODE MA132WK (TX)
D17 1790001250 S.DIODE MA2S111-(TX)
D18 1790001590 S.DIODE MA6S718 (TX)
D19 1790001560 S.DIODE 1SS372 (TE85R)
D20 1790001560 S.DIODE 1SS372 (TE85R)
D201 1750000540 S.DIODE RB060L-40 TE-25
D202 1790001240 S.DIODE MA2S728-(TX)
D203 1790000860 S.DIODE MA133 (TX)
D204 1790000670 S.DIODE SB07-03C-TB
D301 1790001250 S.DIODE MA2S111-(TX)
D800 1750000690 S.DIODE MA727-(TX)
D801 1750000690 S.DIODE MA727-(TX)
D802 1750000690 S.DIODE MA727-(TX)
D804 1750000540 S.DIODE RB060L-40 TE-25
D805 1750000540 S.DIODE RB060L-40 TE-25
D810 1790001260 S.DIODE MA2S077-(TX)
D820 1790001250 S.DIODE MA2S111-(TX)
D901 1720000660 S.VARICAP 1SV288 (TPH2)
D903 1790001250 S.DIODE MA2S111-(TX)
X1 6050010310 S.XTAL CR-613 (4.935 MHz)
X901 6050011010 S.XTAL CR-679 (3.579545 MHz)
L1 6200008630 S.COIL CD54-101KC
L900 6200002040 S.COIL NL 252018T-101J
L901 6200005010 S.COIL NL 252018T-100J
L902 6200005010 S.COIL NL 252018T-100J
L903 6200005010 S.COIL NL 252018T-100J
L904 6200005010 S.COIL NL 252018T-100J
L905 6200005010 S.COIL NL 252018T-100J
