Icom IC-R3

S.=Surface mount
J801 6510022180 S.CONNECTOR 08-6212-024-340-800
DS1 5030001830 LCD A0080
DS2 5040002230 S.LED CL-200YG-C-TS
DS3 5040002230 S.LED CL-200YG-C-TS
DS4 5030001780 LCD ALP210CXX10
DS5 5080000460 CFL 3AE4T4KL2008Y AIC
S2 2230000900 S.SWITCH JPM1990-2013R
T1 5920000740 TRANSFORMER TO-47
T2 5920000770 TRANSFORMER TO-51
W1 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W5 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W915 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8970023650 E.OTHER RX2304 J LEAD SET (2) /LO
EP1 8930052910 LCD CONTACT SRCN-2304-SP-N-W
EP2 0910053004 PCB B 5369D
IC3 1130007610 S.IC µPD3140GS-E1 (DS8)
IC4 1110003470 S.IC µPC2746T-E3
Q21 1590001940 S.TRANSISTOR DTC144EE TL
Q22 1530003260 S.TRANSISTOR 2SC5006-T1
Q23 1530003260 S.TRANSISTOR 2SC5006-T1
Q25 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q31 1560000540 S.FET 2SK880-Y (TE85R)
Q32 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q33 1530003630 S.TRANSISTOR 2SC4617 TLS
Q34 1530003750 S.TRANSISTOR UPA804T-T1
Q853 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q861 1530003260 S.TRANSISTOR 2SC5006-T1
Q862 1530003560 S.TRANSISTOR 2SC5195-T1
Q863 1530003560 S.TRANSISTOR 2SC5195-T1
Q864 1530003560 S.TRANSISTOR 2SC5195-T1
Q870 1560000540 S.FET 2SK880-Y (TE85R)
Q871 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
D41 1720000370 S.VARICAP HVU350TRF
D42 1790001250 S.DIODE MA2S111-(TX)
D61 1790001260 S.DIODE MA2S077-(TX)
D62 1720000650 S.VARICAP 1SV286 (TPH3)
D201 1790001250 S.DIODE MA2S111-(TX)
D202 1720000650 S.VARICAP 1SV286 (TPH3)
D913 1720000700 S.VARICAP 1SV305 (TPL3)
X1 6050010970 S.XTAL CR-674 (12.8 MHz)
L45 6200008380 S.COIL 0.28-1.0-11TR 42N
L62 6910011690 S.COIL ACB1608M-600-T
L63 6200008270 S.COIL 0.26-1.0-5TL 17N
L64 6200008240 S.COIL 0.30-0.9-5TL 14N
L65 6200005700 S.COIL ELJRE 22NG-F
L68 6200006980 S.COIL ELJRE R10G-F
L69 6200005700 S.COIL ELJRE 22NG-F
L917 6200006980 S.COIL ELJRE R10G-F
L918 6200005640 S.COIL ELJRE 6N8Z-F
L919 6200008230 S.COIL 0.30-1.3-5TL 22N
L920 6200005640 S.COIL ELJRE 6N8Z-F
L921 6200005640 S.COIL ELJRE 6N8Z-F
L922 6200005630 S.COIL ELJRE 5N6Z-F
L923 6200005630 S.COIL ELJRE 5N6Z-F
L924 6200005640 S.COIL ELJRE 6N8Z-F
L925 6200005640 S.COIL ELJRE 6N8Z-F
R38 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R39 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R40 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R41 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R42 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R43 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R44 7030009280 S.RESISTOR ERJ2GE 391 X (390 Ω)
R45 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R46 7030009280 S.RESISTOR ERJ2GE 391 X (390 Ω)
R47 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ)
R48 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R49 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R50 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R51 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R52 7030008410 S.RESISTOR ERJ2GEJ 392 X (3.9 kΩ)
R69 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R87 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R88 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R89 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω)
R90 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R104 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R119 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R120 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R121 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R122 7030008410 S.RESISTOR ERJ2GEJ 392 X (3.9 kΩ)
R123 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R124 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R125 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ)
R126 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
R127 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R128 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R129 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R154 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R160 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
R162 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ)
R163 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R188 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R195 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω)
R196 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R197 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R198 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R921 7030005710 S.RESISTOR ERJ2GEJ 121 X (120 Ω)
R922 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R923 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R940 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R941 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R943 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R944 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R945 7030009160 S.RESISTOR ERJ2GEJ 181 X (180 Ω)
R946 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R947 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R948 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R949 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R950 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R951 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R952 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R970 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R971 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R972 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
C78 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C79 4030013850 S.CERAMIC ECUE1E102KBQ
C80 4030014020 S.CERAMIC ECUE1H020BCQ
C81 4030013850 S.CERAMIC ECUE1E102KBQ
C82 4550006200 S.TANTALUM ECST0JY106R
C100 4030014170 S.CERAMIC ECUE1H330JCQ
C121 4030014180 S.CERAMIC ECUE1H470JCQ
C122 4030014180 S.CERAMIC ECUE1H470JCQ
C123 4030014180 S.CERAMIC ECUE1H470JCQ
C124 4030013850 S.CERAMIC ECUE1E102KBQ
C125 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C126 4550006810 S.TANTALUM ECST1VY473R
C127 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C128 4550006810 S.TANTALUM ECST1VY473R
C129 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C130 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
6 - 9
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[VCO UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[VCO UNIT]
