Icom IC-R3

S.=Surface mount
C131 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C132 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C133 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C134 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C135 4030013850 S.CERAMIC ECUE1E102KBQ
C136 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C137 4030013850 S.CERAMIC ECUE1E102KBQ
C138 4030014120 S.CERAMIC ECUE1H100CCQ
C139 4030014140 S.CERAMIC ECUE1H150JCQ
C140 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C145 4030013850 S.CERAMIC ECUE1E102KBQ
C154 4030014340 S.CERAMIC ECUE1H390JCQ
C156 4030013850 S.CERAMIC ECUE1E102KBQ
C157 4030014110 S.CERAMIC ECUE1H080CCQ
C158 4030013850 S.CERAMIC ECUE1E102KBQ
C160 4030013850 S.CERAMIC ECUE1E102KBQ
C161 4030013850 S.CERAMIC ECUE1E102KBQ
C162 4550006200 S.TANTALUM ECST0JY106R
C163 4030013850 S.CERAMIC ECUE1E102KBQ
C164 4030013850 S.CERAMIC ECUE1E102KBQ
C165 4030014000 S.CERAMIC ECUE1H1R5BCQ
C166 4030013850 S.CERAMIC ECUE1E102KBQ
C173 4030013850 S.CERAMIC ECUE1E102KBQ
C178 4030013850 S.CERAMIC ECUE1E102KBQ
C180 4030013850 S.CERAMIC ECUE1E102KBQ
C182 4030013850 S.CERAMIC ECUE1E102KBQ
C183 4030014000 S.CERAMIC ECUE1H1R5BCQ
C237 4030013850 S.CERAMIC ECUE1E102KBQ
C249 4030013850 S.CERAMIC ECUE1E102KBQ
C250 4030014110 S.CERAMIC ECUE1H080CCQ
C251 4030014070 S.CERAMIC ECUE1H040BCQ
C252 4030014110 S.CERAMIC ECUE1H080CCQ
C253 4030014020 S.CERAMIC ECUE1H020BCQ
C254 4030014070 S.CERAMIC ECUE1H040BCQ
C255 4030013850 S.CERAMIC ECUE1E102KBQ
C256 4030013850 S.CERAMIC ECUE1E102KBQ
C257 4030013850 S.CERAMIC ECUE1E102KBQ
C258 4030013850 S.CERAMIC ECUE1E102KBQ
C259 4030013850 S.CERAMIC ECUE1E102KBQ
C260 4030013850 S.CERAMIC ECUE1E102KBQ
C955 4030014220 S.CERAMIC ECUE1E471KBQ
C956 4550006950 S.TANTALUM ECST0JX476R
C957 4030014220 S.CERAMIC ECUE1E471KBQ
C958 4030014080 S.CERAMIC ECUE1H050BCQ
C959 4030014100 S.CERAMIC ECUE1H070CCQ
C960 4030014000 S.CERAMIC ECUE1H1R5BCQ
C964 4030014120 S.CERAMIC ECUE1H100CCQ
C965 4030013850 S.CERAMIC ECUE1E102KBQ
C967 4030014090 S.CERAMIC ECUE1H060CCQ
C968 4030014240 S.CERAMIC ECUE1H180JCQ
C969 4030009820 S.CERAMIC C1005 JB 1C 103K-T-A
C971 4030014220 S.CERAMIC ECUE1E471KBQ
C972 4030013980 S.CERAMIC ECUE1H010BCQ
C973 4030014100 S.CERAMIC ECUE1H070CCQ
C974 4030014000 S.CERAMIC ECUE1H1R5BCQ
C975 4030014240 S.CERAMIC ECUE1H180JCQ
C976 4030014030 S.CERAMIC ECUE1H2R5BCQ
C977 4030014000 S.CERAMIC ECUE1H1R5BCQ
C978 4030013980 S.CERAMIC ECUE1H010BCQ
C979 4030014060 S.CERAMIC ECUE1H3R5BCQ
C981 4030014020 S.CERAMIC ECUE1H020BCQ
C982 4030014080 S.CERAMIC ECUE1H050BCQ
C983 4030014220 S.CERAMIC ECUE1E471KBQ
C984 4030014020 S.CERAMIC ECUE1H020BCQ
C991 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
J1 6510022350 CONNECTOR IMSA-9230B-1-09Z114-T
J2 6510022350 CONNECTOR IMSA-9230B-1-09Z114-T
EP1 0910053023 PCB B 5371C
EP100 6910012350 S.BEAD MMZ1608Y 102BT
EP101 6910012350 S.BEAD MMZ1608Y 102BT
IC1 1110003310 S.IC µPC1688G-T1
IC2 1190001370 S.IC AN8945SBS-E1
IC21 1190001190 S.IC µPC1663GV-E1
IC22 1110005080 S.IC NJM2246M-TE3
Q21 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q23 1590001470 S.TRANSISTOR UN9213 (TX)
Q41 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q51 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q71 1530002280 S.TRANSISTOR 2SC4081 T107 S
D1 1790001260 S.DIODE MA2S077-(TX)
D2 1750000750 S.VARICAP MA376-(TX)
D3 1790001250 S.DIODE MA2S111-(TX)
D4 1750000750 S.VARICAP MA376-(TX)
D41 1790001260 S.DIODE MA2S077-(TX)
D51 1720000660 S.VARICAP 1SV288 (TPH2)
D52 1720000660 S.VARICAP 1SV288 (TPH2)
FI1 2040001630 S.LC LFSC25N12B0426B
L1 6200005600 S.COIL ELJRE 3N3Z-F
L2 6200008490 S.COIL 0.30-0.9-3TR 7.5N
L3 6200006980 S.COIL ELJRE R10G-F
L21 6200001620 S.COIL ELJFC 1R0K-F
L41 6200001620 S.COIL ELJFC 1R0K-F
L51 6200007420 S.COIL ELJFC 101K-F 100U
L52 6200003270 S.COIL NL 252018T-R56J
R1 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R2 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R3 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R4 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R6 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R8 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R9 7030009280 S.RESISTOR ERJ2GE 391 X (390 Ω)
R10 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
R12 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R13 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R14 7030009200 S.RESISTOR ERJ2GEJ 390 X (39 Ω)
R15 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω)
R16 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
R21 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R23 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R24 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R28 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R30 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R31 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R33 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R35 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R36 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R37 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R38 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R39 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R40 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R41 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R42 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R43 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R44 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R45 7030008370 S.RESISTOR ERJ2GEJ 561 X (560 Ω)
R46 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R47 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R51 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ)
R52 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R53 7030008370 S.RESISTOR ERJ2GEJ 561 X (560 Ω)
R54 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R55 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R71 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ)
R73 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R74 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R75 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ)
R77 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R78 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R79 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R81 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
6 - 10
REF ORDER
DESCRIPTION
NO. NO.
[VCO UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[FM-TV UNIT] [OTH-2] only
