2-5
+3 V REGULETOR
(IC22)
+2.5 V REGULETOR
(IC23)
+2.5 V REGULETOR
(IC24)
ELECTRONIC VOLUME
(IC8)
BUFF AMPLIFIER
(IC9)
AF POWER AMPLIFIER
(IC10)
J2 [EXT SP]
FM HPF
(IC2)
+3 V REGULETOR
(IC20)
+3 V REGULETOR
(IC20)
+3 V REGULETOR
(IC19)
+2.5 V REGULETOR
(IC16)
FM LPF
(IC3)
W1
MODE SWITCH
(IC5)
MODE SWITCH
(IC6)
WFM/AM LPF
(IC1)
AF UNIT
REAR PANEL
• AF UNIT (TOP VIEW)
