2-6
+4.2 V REGURATOR
(IC17)
MODE SWITCH: A-Band
(IC17)
MODE SWITCH: A-Band
(IC4)
+3 V REGURATOR
(IC15)
I/O PORT
(IC12)
I/O PORT
(IC11)
J1
• AF UNIT (BOTTOM VIEW)
SHIELD PLATE
