2-7
BAR ANTENNA
(EP1: MAIN UNIT)
ENCODERAR
(S1: LOGIC/-1 UNIT)
ANTENNA CONECTOR
(J1: CHASSIS UNIT)
• REAR PANEL (INSIDE VIEW)
GPS ANTENNA
(EP1: CHASSIS UNIT)
Below the antenna plate.
