Icom IC-R75 - Page 28

S.=Surface mount
J884 6450001560 CONNECTOR PD-72
J1081 6510007020 CONNECTOR TMP-J01X-V6
J1221 6510018970 S.CONNECTOR B4B-PH-SM3-TB
J1231 6510019970 S.CONNECTOR 52808-1090
J1271 6510019190 S.CONNECTOR 52365-0891
J1311 6450001800 CONNECT JPJ1044-01-010
J1321 6450000140 CONNECTOR HSJ0807-01-010
J1351 6450001700 CONNECTOR HEC0740-010010
J1501 6510019980 S.CONNECTOR 52808-1690
J1521 6510019980 S.CONNECTOR 52808-1690
J1522 6510008370 CONNECTOR BBH-1
J1541 6510019980 S.CONNECTOR 52808-1690
J1561 6510019980 S.CONNECTOR 52808-1690
J1701 6450000140 CONNECTOR HSJ0807-01-010
J1751 6510021240 CONNECTOR DELC-J9SAF-23L9
F1351 5210000050 FUSE FGB 3A
F1352 5220000230 HOLDER S-N5054 #01
F1353 5220000230 HOLDER S-N5054 #01
BT1521 3020000110 LITHIUM CR2032
WS1 8600036540 CABLE RX2240 P1241*J1241MA
EP1 0910051114 PCB B 5273D
IC21 1140003641 S.IC SC-1246
IC22 1110004460 S.IC µPB1509GV-E1
IC23 1130003830 S.IC TC7S04F (TE85R)
IC151 1140004550 S.IC M65343FP/SC1287
IC201 1140004550 S.IC M65343FP/SC1287
Q1 1530002570 S.TRANSISTOR 2SC4405-3-TL
Q2 1530002570 S.TRANSISTOR 2SC4405-3-TL
Q3 1590000680 S.TRANSISTOR DTC114EUA T106
Q4 1590000680 S.TRANSISTOR DTC114EUA T106
Q21 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q71 1560000490 S.FET 2SK508 K52 T2B
Q72 1590000680 S.TRANSISTOR DTC114EUA T106
Q81 1560000490 S.FET 2SK508 K52 T2B
Q82 1590000680 S.TRANSISTOR DTC114EUA T106
Q91 1530002570 S.TRANSISTOR 2SC4405-3-TL
Q92 1590001330 S.TRANSISTOR DTA114EUA T106
Q93 1590000680 S.TRANSISTOR DTC114EUA T106
Q96 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q97 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q151 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q201 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
D1 1750000520 S.DIODE DAN222TL
D2 1750000550 S.DIODE 1SS355 TE-17
D71 1720000390 S.VARICAP KV1470TL
D72 1790000620 S.DIODE MA77 (TX)
D81 1720000390 S.VARICAP KV1470TL
D82 1790000620 S.DIODE MA77 (TX)
D91 1790000620 S.DIODE MA77 (TX)
D92 1790000620 S.DIODE MA77 (TX)
D93 1790001640 S.DIODE 1SS373 (TPH3)
D94 1790001640 S.DIODE 1SS373 (TPH3)
X1 6050005711 XTAL CR-275A (30.00000 MHz)
L1 6170000230 COIL LW-25
L2 6150004370 COIL LS-472C (C-15045)
L3 6200003950 S.COIL HF50ACC 322513-T
L4 6150004250 COIL LS-471A (C-14922)
5 - 9
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
L5 6150004250 COIL LS-471A (C-14922)
L22 6200003170 S.COIL NL 322522T-330J
L23 6200003180 S.COIL NL 322522T-390J
L24 6200003180 S.COIL NL 322522T-390J
L25 6200001830 S.COIL NL 322522T-100J
L26 6200003190 S.COIL NL 322522T-470J
L27 6200003190 S.COIL NL 322522T-470J
L71 6170000230 COIL LW-25
L72 6190001370 COIL E544GN-110254
L73 6170000230 COIL LW-25
L81 6170000230 COIL LW-25
L82 6190001280 COIL E544GN-110248
L83 6170000230 COIL LW-25
L91 6180002960 S.COIL NL 322522T-R18J-3
L92 6180002980 S.COIL NL 322522T-056J
L93 6180002970 S.COIL NL 322522T-068J
L94 6200001830 S.COIL NL 322522T-100J
L151 6200003130 S.COIL NL 322522T-120J
L152 6200003140 S.COIL NL 322522T-150J
L153 6200001830 S.COIL NL 322522T-100J
L201 6200005490 S.COIL NL 322522T-331J
L202 6200008640 S.COIL NL 322522T-391J
L203 6200001830 S.COIL NL 322522T-100J
L204 6200003640 S.COIL MLF1608K 100K-T
L205 6200003640 S.COIL MLF1608K 100K-T
R1 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R2 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R3 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R4 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R5 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R6 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R7 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R8 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R9 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R10 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R11 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R12 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R21 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R22 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R23 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R24 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R25 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R26 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R27 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R28 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R29 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R30 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R31 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R32 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R33 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R34 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R35 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R36 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R37 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R38 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R39 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R40 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R41 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R42 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R43 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R44 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R45 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R46 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R47 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R48 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R50 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R51 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R52 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R53 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R54 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R55 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R71 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R72 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R73 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R75 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R76 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R78 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R79 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R80 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[PLL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[PLL UNIT]
