Icom IC-R75 - Page 29

5 - 10
S.=Surface mount
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R83 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R85 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R86 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R91 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R92 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R93 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R94 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R95 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R96 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R97 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R98 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R99 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R100 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R101 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R102 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R103 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R104 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R107 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R108 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R109 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R110 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R111 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R112 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R113 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R114 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R115 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R116 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R117 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R151 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R152 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R153 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R154 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R155 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R156 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R157 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R158 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R159 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R160 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R161 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R162 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R163 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R164 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R165 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R166 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R167 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R168 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R169 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R170 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R171 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R172 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R178 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R180 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R181 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R182 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R183 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R201 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R202 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R203 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R204 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R205 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R206 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R207 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R208 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R209 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R210 7030005400 S.RESISTOR RR0816P-202-D (2 kΩ)
R211 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R212 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R213 7030005370 S.RESISTOR RR0816P-202-B (2 kΩ)
R214 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R215 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R216 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R217 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R218 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R219 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R220 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R221 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R222 7030005380 S.RESISTOR RR0816P-102-B (1 kΩ)
R228 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R230 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R231 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R232 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[PLL UNIT]
R233 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R235 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R236 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
C1 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C3 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C4 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C5 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C6 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C7 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C8 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C9 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C10 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C11 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C12 4030006910 S.CERAMIC C1608 CH 1H 0R5C-T-A
C13 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C14 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C15 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C16 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C21 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C23 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C24 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C25 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C26 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C27 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C28 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C29 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C30 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C31 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C32 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C33 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C34 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C35 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C36 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C37 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C38 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C39 4030011540 S.CERAMIC C1608 CH 1H 750J-T-A
C40 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C41 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C42 4030006930 S.CERAMIC C1608 CH 1H 020C-T-A
C43 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C44 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C50 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C51 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C52 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C53 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C54 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C55 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C56 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C57 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C58 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C59 4030011840 S.CERAMIC C1608 CH 1H 241J-T-A
C60 4030009580 S.CERAMIC C1608 JB 1H 681K-T-A
C71 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C72 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C73 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C74 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C75 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C76 4610001830 S.TRIMMER TZBX4N100BA110T00
C77 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C78 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C79 4030006930 S.CERAMIC C1608 CH 1H 020C-T-A
C80 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C81 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C82 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C83 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C84 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C85 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C86 4610001830 S.TRIMMER TZBX4N100BA110T00 10P
C87 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C88 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C89 4030010780 S.CERAMIC C1608 CH 1H 1R5C-T-A
C90 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C91 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C92 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C93 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C94 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C95 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C96 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C97 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C98 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
REF ORDER
DESCRIPTION
NO. NO.
[PLL UNIT]
