Icom IC-UR8050 - Page 15

S.=Surface mount
D4 1790001200 S.DIODE MA6S121(TX)
D5 1790001200 S.DIODE MA6S121(TX)
D6 1790001200 S.DIODE MA6S121(TX)
D7 1790001200 S.DIODE MA6S121(TX)
D8 1790001200 S.DIODE MA6S121(TX)
D9 1790001200 S.DIODE MA6S121(TX)
D10 1790001200 S.DIODE MA6S121(TX)
D11 1790001200 S.DIODE MA6S121(TX)
D12 1790001200 S.DIODE MA6S121(TX)
D13 1790001200 S.DIODE MA6S121(TX)
D14 1790001200 S.DIODE MA6S121(TX)
D15 1790001200 S.DIODE MA6S121(TX)
D16 1790001200 S.DIODE MA6S121(TX)
D17 1750000290 S.DIODE 1SS300 (TE85R)
D18 1750000550 S.DIODE 1SS355 TE-17
D19 1160000060 S.DIODE DAN202U T107
X1 6050009300 S.XTAL CR-505 (4 MHz)
L1 6170000140 COIL LW-15
R1 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R2 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R3 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R4 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R5 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R6 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R7 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R8 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R9 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R10 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R11 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R12 7410000720 S.ARRAY EXB-V8V 473JV (47 KΩ)
R13 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R14 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 KΩ)
R15 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R16 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R17 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 KΩ)
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R19 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R20 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R21 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R22 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 KΩ)
R23 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 KΩ)
R24 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 KΩ)
R25 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R26 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R27 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R28 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R29 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R30 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223
R31 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R32 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R34 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R35 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223
R36 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R37 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R39 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R40 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 KΩ)
R41 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R42 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R43 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R44 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 KΩ)
R45 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R46 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R47 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223
R48 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R49 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 KΩ)
R50 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 KΩ)
R51 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R52 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R54 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R55 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 KΩ)
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R57 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R59 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R60 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R61 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471
R62 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 KΩ)
R63 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R65 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 KΩ)
R66 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R67 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R69 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R70 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R71 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R72 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 KΩ)
R73 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 KΩ)
R74 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R75 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 KΩ)
R76 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 KΩ)
R77 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R78 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R79 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 KΩ)
R80 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R81 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R82 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R83 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471
R84 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R85 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R86 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 KΩ)
R87 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 KΩ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 KΩ)
R89 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R90 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 KΩ)
R91 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R92 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 KΩ)
R93 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 KΩ)
R94 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 KΩ)
R97 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 KΩ)
R98 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R99 7310002770 S.TRIMMER RV-153 (RH03A3AN4X02A) 333
R100 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 KΩ)
R101 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 KΩ)
R102 7310002770 S.TRIMMER RV-153 (RH03A3AN4X02A) 333
R103 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R104 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 KΩ)
R105 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R106 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R107 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R108 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R109 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R110 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R111 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R112 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R113 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R114 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R115 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R116 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R117 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R118 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R119 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R120 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R121 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R122 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R123 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R124 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R125 7410000950 S.ARRAY EXB-V8V 102JV
R126 7410000950 S.ARRAY EXB-V8V 102JV
R127 7410000950 S.ARRAY EXB-V8V 102JV
R128 7410000950 S.ARRAY EXB-V8V 102JV
R129 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 KΩ)
R130 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 KΩ)
R131 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 KΩ)
R132 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 KΩ)
R133 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 KΩ)
R134 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 KΩ)
C1 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C2 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C3 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C4 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C6 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C7 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C8 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C9 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C10 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
4 - 2
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
