SECTION 1 SPECIFICATIONS
1 - 1
All stated specifications are subject to change without notice or obligation.
M GENERAL
• Frequency range : 400–430 MHz
• Mode : FM (F3)
• Frequency Resolution : 5 or 12.5 kHz (Selectable)
• Antenna impedance : 50 Ω
• Power supply requirement : DC 13.8 V ± 15 % (negative ground)
• Current drain (at 13.8 V DC) :
• Usable temperature range : – 20 ˚C to + 60 ˚C (– 4 ˚F to + 140 ˚F)
• Frequency stability : ± 2.5 ppm (– 20 ˚C to + 60 ˚C; – 4 ˚F to + 140 ˚F)
• Dimensions : 425 (W)
× 149 (H) × 368 (D) mm; 16.7 (W) × 5.9 (H) × 14.5 (D) inch
(Projections not included)
• Weight : 12 kg (26.5 lb)
M TRANSMITTER
• Output power : 45 W (Typical)
• Modulation system : Variable reactance modulation and reference modulation
• Max. frequency deviation : 2.5 kHz (Narrow)
5.0 kHz (Wide)
• Spurious emissions : less than – 70 dB
• Microphone impedance : 600 Ω
M RECEIVER
• Receiving system : Double conversion superheterdyne
• Intermediate frequency : 1st 30.875 MHz
2nd 455 kHz
• Sensitivity : less than 0.32 µV for 12 dB SINAD
• Squelch sensitivity : less than 0.32 µV
• Sprious and image rejection : more than 70 dB
• Audio output power : 1.7 W at 10 % distortion with an 8 Ω load
• Audio output impedance : 8 Ω
Transmit
Receive
15 A
0.7 A
2.0 A
Standby
Max power
