Icom ID-1

6 - 8
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
EP403 6910012350 S.BEA MMZ1608Y 102BT B 20.8/63
EP404 6910012350 S.BEA MMZ1608Y 102BT T 14.4/60.4
EP405 6910012350 S.BEA MMZ1608Y 102BT T 21.3/66.3
EP470 6910012350 S.BEA MMZ1608Y 102BT T 16.4/68.2
EP482 6910012350 S.BEA MMZ1608Y 102BT B 12.9/82.8
EP550 6910012350 S.BEA MMZ1608Y 102BT B 24.6/39.8
EP551 6910012350 S.BEA MMZ1608Y 102BT B 35.1/26.6
EP552 6910012350 S.BEA MMZ1608Y 102BT B 27.1/48.7
EP553 6910012350 S.BEA MMZ1608Y 102BT B 18/48.1
EP721 6910012350 S.BEA MMZ1608Y 102BT B 32.1/85.5
EP1601 6910014690 S.BEA MPZ1608S221A-T T 114.3/16.4
EP1602 6910014690 S.BEA MPZ1608S221A-T T 105.3/18.2
EP1603 6910014690 S.BEA MPZ1608S221A-T T 104.4/14
EP1604 6910014690 S.BEA MPZ1608S221A-T T 109/12.4
EP1606 6910014690 S.BEA MPZ1608S221A-T B 114.3/12.3
EP1607 6910014690 S.BEA MPZ1608S221A-T T 113.4/13.9
EP1608 6910014690 S.BEA MPZ1608S221A-T T 102.7/11.8
EP1609 6910014690 S.BEA MPZ1608S221A-T B 107.4/8.6
EP1750 6910012350 S.BEA MMZ1608Y 102BT B 27.8/124
EP1751 6910012350 S.BEA MMZ1608Y 102BT B 27.8/125.5
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
Q501 1590000430 S.TR DTC144EUA T106 T 76.6/66.1
Q502 1530002280 S.TR 2SC4081 T106 S T 67.9/72.3
Q503 1520000200 S.TR 2SB798-T2 DK B 74.3/68.5
Q504 1530002280 S.TR 2SC4081 T106 S B 70/74.5
Q550 1590000430 S.TR DTC144EUA T106 B 15.5/49.9
Q551 1530002280 S.TR 2SC4081 T106 S B 15.7/64.1
D50 1790001240 S.DIO MA2S728-(TX) T 59.3/66.6
D51 1750000550 S.DIO 1SS355 TE-17 B 1.4/48.1
D52 1750000550 S.DIO 1SS355 TE-17 B 50.1/60.5
D53 1750000550 S.DIO 1SS355 TE-17 T 46.6/59.5
D54 1750000550 S.DIO 1SS355 TE-17 B 48.1/66.7
D55 1730002280 S.ZEN MA8091-M (TX) T 12.7/43.9
D201 1790001240 S.DIO MA2S728-(TX) B 39.6/51.1
D350 1720000360 S.DIO HSU88TRF T 85.3/24.3
D351 1720000360 S.DIO HSU88TRF T 87.7/19.4
D501 1790000670 S.DIO SB07-03C-TB T 72.2/69.6
D502 1750000550 S.DIO 1SS355 TE-17 T 71.2/72.3
D503 1790000670 S.DIO SB07-03C-TB T 99.4/65.9
D504 1790000670 S.DIO SB07-03C-TB B 110.2/74.1
X50 6050011290 S.XTL CR-715 (6 MHz) T 44.4/47.2
X100 6050011300 S.XTL CR-716 (20 MHz) T 99.1/55.5
X200 6050011240 S.XTL CR-708 (16.384 MHz) T 19/34.3
X201 6050011700 S.XTL CR-760 (9.8304 MHz) T 37.2/33.3
X550 6050011290 S.XTL CR-715 (6 MHz) T 3.4/55.5
L50 6200005740 S.COL ELJRE 47NG-F T 65.2/67.6
L51 6200005740 S.COL ELJRE 47NG-F T 48.4/46
L100 6200005740 S.COL ELJRE 47NG-F B 111.3/56
L101 6200005740 S.COL ELJRE 47NG-F B 111.3/57.3
L102 6200005740 S.COL ELJRE 47NG-F T 87/52.4
L103 6200005740 S.COL ELJRE 47NG-F B 108.5/27.6
L114 6200006990 S.COL ELJRE 56NG-F B 11.9/70.6
L115 6200006990 S.COL ELJRE 56NG-F B 13.4/70.6
L116 6200006990 S.COL ELJRE 56NG-F B 14.9/70.6
L117 6200006990 S.COL ELJRE 56NG-F B 16.2/70.6
L119 6200006990 S.COL ELJRE 56NG-F B 19.5/70.6
L120 6200006990 S.COL ELJRE 56NG-F B 20.9/70.6
L121 6200006990 S.COL ELJRE 56NG-F B 22.7/70.6
L150 6200002040 S.COL NL 252018T-101J T 99.7/17
L210 6200005740 S.COL ELJRE 47NG-F T 70.6/67.4
L211 6200005740 S.COL ELJRE 47NG-F B 47.7/53.7
L214 6200005740 S.COL ELJRE 47NG-F B 49/56.4
L420 6200003590 S.COL EXCCL3225U1 B 30.9/74
L421 6200003590 S.COL EXCCL3225U1 B 38.8/73.9
L500 6190001560 S.COL CDRH5D18-101NC T 104.3/74
L501 6190001560 S.COL CDRH5D18-101NC T 104.3/66.8
L510 6200003590 S.COL EXCCL3225U1 B 108.8/70.7
L550 6200002040 S.COL NL 252018T-101J T 12.5/70.5
L551 6200005740 S.COL ELJRE 47NG-F T 15.6/71.3
L552 6200006990 S.COL ELJRE 56NG-F B 14.6/55.8
R1 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 2.9/20.9
R2 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 2.9/23.5
R12 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 37.4/57.5
R13 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 37.1/61.8
R14 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 35.8/61.8
R15 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 34.5/61.8
R16 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 33.2/61.8
R17 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 35.3/57.5
R18 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 35.5/40.5
R25 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 14.8/22.7
R50 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 44.4/69.8
R51 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 47.2/65
R53 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 48.5/62.4
R54 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 15.5/44.4
R55 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 15.5/43
R57 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 3.7/43.9
R58 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 15.4/46.2
R59 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 2.4/43.9
R60 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 47.7/56.4
R61 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 45.8/56.4
R62 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 49.3/45.1
R63 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 53.9/44.5
R64 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 61.5/39.7
R65 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 62.8/39.7
R66 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 72.5/35.1
R67 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 72.5/37.7
R68 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 9.1/45.6
R69 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 8.2/46.7
R70 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 4.4/45.8
R71 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 4/50.5
R72 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 6.3/51.4
R73 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 7.1/49.6
R74 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 46.3/68.7
R75 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 48.1/69
R76 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 67.9/38.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1130010030 S.IC µPD9930G-22 T 8.5/32.4
IC2 1130010920 S.IC AMBE-2020 T 31.8/51
IC3 1130006890 S.IC TC7S04FU (TE85R) B 30.7/46.1
IC4 1180002370 S.REG R1111N321B-TR T 33.2/38.7
IC50 1140010090 S.IC µPD70F3102AGJ-33-8EU T 61.6/54
IC51 1130007280 S.IC TC7S32FU (TE85R) T 45.3/65.2
IC52 1110005730 S.IC S-80928CNMC-G8Y-T2 B 54.3/42.2
IC53 1130007110 S.IC TC7W04FU (TE12L) T 44.6/62.1
IC54 1140008650 S.IC HN58X2464TI T 45.2/56.4
IC55 1130010630 S.IC SN74AHCT541PWR B 43/36.3
IC56 1190001340 S.IC M62334FP 600C T 59.8/37.1
IC57 1190001340 S.IC M62334FP 600C T 68.2/37
IC58 1110002860 S.IC TA75S393F (TE85R) B 4/48.1
IC100 1130010620 S.IC SN74AHC541PWR B 109.6/49.6
IC101 1130007110 S.IC TC7W04FU (TE12L) T 106.1/56.2
IC102 1130008710 S.IC TC7SET04FU (TE85L) T 110.9/55.3
IC103 1130010630 S.IC SN74AHCT541PWR T 108.9/49.3
IC104 1120002840 S.IC RTL8019AS T 87.7/39.1
IC105 1130010580 S.IC µPD43256BGW-70LL-9JL T 108.7/37.2
IC150 1110005430 S.IC CMX589AD5 T 98.2/11.4
IC151 1130008710 S.IC TC7SET04FU (TE85L) T 89.1/16.9
IC152 1130004200 S.IC TC4S66F (TE85R) B 103.9/7.5
IC153 1130004200 S.IC TC4S66F (TE85R) B 100.9/13
IC200 1120002870 S.IC XCS20XL-4TQ144I T 32.1/18.9
IC201 1130006890 S.IC TC7S04FU (TE85R) B 36.5/54.2
IC202 1130008360 S.IC TC7SHU04FU (TE85L) T 25.6/32.9
IC203 1130006890 S.IC TC7S04FU (TE85R) B 35.4/31.1
IC300 1110005290 S.IC NJM2115V-TE1 T 58.6/19.4
IC301 1110005290 S.IC NJM2115V-TE1 T 57.2/30.5
IC302 1110005290 S.IC NJM2115V-TE1 T 68.4/20.7
IC350 1130006220 S.IC TC4W53FU (TE12L) T 84.4/19.1
IC351 1110003780 S.IC NJM2902V-TE1 T 90.6/23.1
IC352 1130006220 S.IC TC4W53FU (TE12L) T 81.2/23.6
IC353 1130008560 S.IC TC75S51F (TE85L) T 100.8/23.8
IC354 1130006220 S.IC TC4W53FU (TE12L) T 104.8/18.8
IC355 1110002750 S.IC TA75S01F (TE85R) B 87.5/17.5
IC500 1180001070 S.IC TA7805F (TE16L) T 86.3/73.9
IC502 1180002390 S.REG S-812C33AMC-C2N-T2 T 92.8/66
IC503 1110005440 S.IC NJM2374AM-TE1 T 110.5/70.6
IC504 1180002390 S.REG S-812C33AMC-C2N-T2 T 64.3/74.8
IC550 1130010570 S.IC FT8U232AM T 11.8/61.4
IC551 1130009570 S.IC BR93LC46F-WE2 T 12.8/52.2
IC552 1110005820 S.IC R3112N281A-TR T 20.9/60
IC553 1130007280 S.IC TC7S32FU (TE85R) B 10.4/49
Q50 1530002280 S.TR 2SC4081 T106 S B 8.3/43.6
Q51 1510000770 S.TR 2SA1586-GR (TE85R) B 5.7/43.9
Q52 1590000430 S.TR DTC144EUA T106 B 7.9/47.6
Q100 1590000430 S.TR DTC144EUA T106 T 79/26.4
Q101 1590001980 S.TR XP4315 (TX) B 42/7.9
Q102 1590001980 S.TR XP4315 (TX) B 39.5/7.9
Q103 1590000430 S.TR DTC144EUA T106 B 67.7/6.4
Q150 1590001400 S.TR XP1214 (TX) T 91.3/12.8
Q151 1590001400 S.TR XP1214 (TX) B 97.2/6.4
Q153 1590000430 S.TR DTC144EUA T106 B 76.3/24.3
Q154 1590000430 S.TR DTC144EUA T106 B 106.3/12.5
Q155 1590000430 S.TR DTC144EUA T106 B 74.5/20.6
Q156 1590000430 S.TR DTC144EUA T106 B 72/22.4
Q400 1590000430 S.TR DTC144EUA T106 B 73.3/14.4
Q500 1520000200 S.TR 2SB798-T2 DK T 80.3/63.6
