Icom ID-1

6 - 9
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R78 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) T 50.9/43.3
R79 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) T 48.6/50.2
R100 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 76.5/26.2
R101 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 88/27.8
R102 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 88/26.5
R105 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 95.8/55.9
R106 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 95.8/53.1
R107 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) T 81.7/53.1
R108 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 87.5/50.6
R110 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 52.3/8
R111 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) B 90.3/44.5
R112 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) B 89/44.5
R113 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 42.1/5.9
R114 7030003420 S.RES ERJ3GEYJ 681 V (680
Ω
) B 39.5/5.9
R115 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 110.9/54.7
R116 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 106.3/57.8
R146 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 79.1/23.5
R148 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 105.5/9.9
R149 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 88.4/14.2
R150 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 97.9/11
R151 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 97.9/9.7
R152 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 97.9/12.3
R153 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 97.9/14.9
R154 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 97.9/13.6
R155 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 92.4/15.3
R156 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 90.7/8.2
R157 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 95.3/8.8
R158 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 100.8/7.5
R159 7030009340 S.RES ERJ3GEYJ 275V (2.7 M
Ω
) B 99.7/10.1
R199 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 32.7/53.4
R200 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 28.1/32
R201 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 22.4/32.8
R202 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 45.2/9.4
R203 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 31.6/5.8
R204 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 39/5.8
R205 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 24.3/23.2
R206 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 18.2/24.7
R207 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 18.9/26.1
R208 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 34.8/34.8
R209 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 35.6/33
R210 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 41.5/33.3
R211 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 37.8/52
R250 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 52.9/5.8
R251 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/5.8
R252 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/6.6
R253 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/7.1
R254 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.5/7.9
R255 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/8.4
R256 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/9.2
R257 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/9.7
R258 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.5/10.5
R259 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/11
R260 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/11.8
R261 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/12.3
R262 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.5/13.1
R263 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/13.6
R264 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/14.4
R265 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/14.9
R266 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.5/15.7
R267 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/16.2
R268 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/17
R269 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/17.5
R270 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.5/18.3
R271 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/18.8
R272 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 52.7/20.2
R273 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/20.2
R274 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/20.7
R275 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/21.5
R276 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.1/22.1
R277 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/22.8
R278 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/23.3
R279 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/24.1
R280 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.1/24.7
R281 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/25.4
R282 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/25.9
R283 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/26.7
R284 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.1/27.3
R285 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/28
R286 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/28.5
R287 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/29.3
R288 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.1/29.9
R289 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/30.6
R290 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 50.8/31.1
R291 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/31.9
R292 7030005321 S.RES ERA3YED 103V (10 k
Ω
) T 52.1/32.7
R293 7030005661 S.RES ERA3YED 203V (20 k
Ω
) T 48.9/33.2
R300 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 60.7/14.9
R301 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 56.4/22.1
R302 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) T 61.8/22.1
R303 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) T 63.7/19.4
R304 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 67.4/11.7
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R305 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 67.4/13
R306 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 63.7/16.8
R307 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 63.7/14.2
R308 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 64.2/12.1
R310 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 59.3/26
R311 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 55/33.2
R312 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) T 60.4/33.2
R313 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) T 62.3/30.5
R314 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 68.1/28.4
R315 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 68.1/27.1
R316 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 65.5/31
R317 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 68.1/31
R318 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 67.3/25.8
R320 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 61.5/18.3
R348 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 101.4/24
R349 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 77.5/20.4
R350 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 80.1/21.2
R351 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
) T 96.5/25
R352 7030004710 S.RES ERJ3GEYJ 475 V (4.7 M
Ω
) T 98.4/24.4
R353 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
) T 96.5/21.1
R354 7030004710 S.RES ERJ3GEYJ 475 V (4.7 M
Ω
) T 98.4/21.8
R355 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 103.2/21.8
R356 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 84.1/22.7
R357 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 84.9/20.8
R358 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 99.7/18.9
R359 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 84/14.3
R360 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 86.6/15.2
R361 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 87.9/19.9
R362 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 90/19.1
R363 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 90.6/22.9
R364 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 92.4/23.6
R365 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 90.7/19.7
R368 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 82.8/22.7
R400 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 86.1/10.8
R402 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 12.2/15
R403 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 15/5.9
R405 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 15/7.2
R406 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 82/14.2
R407 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 83.3/14.2
R408 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 84.6/14.2
R410 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 16.7/15
R411 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 18/15
R412 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 15.4/15
R413 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 14.1/15
R414 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 10.9/15
R415 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 40.7/68.9
R416 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 82.2/7.3
R417 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 83.5/7.3
R418 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 29.3/68.9
R419 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 28.5/68.9
R420 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 29.8/68.9
R421 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 31.1/68.9
R422 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 75.5/14.2
R423 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 28/68.9
R424 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 42/68.9
R425 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 74.2/14.2
R426 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 71.5/14.2
R427 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 80.9/10.8
R428 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 72.9/14.2
R429 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 78.1/14.2
R430 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 80.7/14.2
R431 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 76.8/14.2
R432 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 75.3/13.4
R433 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 27.2/68.9
R434 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 85.4/8
R435 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 79.4/14.2
R436 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 22/15
R437 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 73.4/12.5
R438 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 87.4/10.8
R439 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 86.5/13.4
R440 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 71.5/17.4
R500 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 80.4/66.8
R501 7030000420 S.RES MCR10EZHJ 2.2 k
Ω
T 78.1/70.1
R502 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) B 72/73.7
R503 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) T 108.4/65.2
R504 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 111/65.2
R505 7030000020 S.RES MCR10EZHJ 1
Ω
(010) B 112.2/71.7
R506 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 66.7/71.9
R507 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 68/71.9
R508 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 68/74.5
R509 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 109.7/65.2
R510 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 69.8/70.1
R511 7030000180 S.RES MCR10EZHJ 22
Ω
(220) T 81.4/68.4
R512 7030000180 S.RES MCR10EZHJ 22
Ω
(220) T 81.4/70.1
R513 7030000420 S.RES MCR10EZHJ 2.2 k
Ω
T 78.1/68.4
R550 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) B 3.9/59.5
R551 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 3.9/57.8
R552 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) B 9.9/56.8
R553 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 9.9/55.5
R556 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 10.5/63.4
R557 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 13.7/60.1
R558 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 17.2/55.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
