6 - 10
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R559 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 12.4/62.6
R560 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 17.8/52.2
R561 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 12.9/52.4
R562 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 15.8/62.2
R563 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 18.8/68.8
R564 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 19.2/63.6
R566 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 12.1/54.3
R567 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 13.6/49
R568 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 11.9/51
R569 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 13.7/62.7
C1 4030011600 S.CER C1608 JB 1E 104K-T T 2.9/19.5
C2 4030007170 S.CER C1608 CH 1H 221J-T T 2.9/22.2
C3 4030011600 S.CER C1608 JB 1E 104K-T T 7.1/22.7
C4 4550006250 S.TAN TEESVA 1A 106M8L T 5.4/21.5
C5 4030011600 S.CER C1608 JB 1E 104K-T T 8.5/22.7
C6 4550006250 S.TAN TEESVA 1A 106M8L T 10.2/22.4
C7 4030010760 S.CER C1608 CH 1H 331J-T T 13.4/21.6
C8 4030009580 S.CER C1608 JB 1H 681K-T T 12.9/23.5
C9 4030011600 S.CER C1608 JB 1E 104K-T T 14.8/20
C11 4030011600 S.CER C1608 JB 1E 104K-T B 11.5/30
C12 4550006250 S.TAN TEESVA 1A 106M8L T 18.3/43.2
C13 4030011600 S.CER C1608 JB 1E 104K-T T 2.3/38.7
C14 4550006250 S.TAN TEESVA 1A 106M8L T 24.2/39.9
C15 4030007090 S.CER C1608 CH 1H 470J-T T 38.9/61.8
C16 4030011600 S.CER C1608 JB 1E 104K-T T 30.8/61.8
C17 4030011600 S.CER C1608 JB 1E 104K-T B 36.6/50.3
C18 4030011600 S.CER C1608 JB 1E 104K-T T 41/49
C19 4030011600 S.CER C1608 JB 1E 104K-T T 32.6/41
C20 4030011600 S.CER C1608 JB 1E 104K-T B 41.7/47.2
C21 4030011600 S.CER C1608 JB 1E 104K-T B 27.9/46.8
C22 4030011600 S.CER C1608 JB 1E 104K-T T 21.6/54.7
C23 4030011600 S.CER C1608 JB 1E 104K-T T 21.6/50.5
C24 4550006250 S.TAN TEESVA 1A 106M8L T 29.9/38.6
C25 4550006250 S.TAN TEESVA 1A 106M8L B 48.9/40.9
C26 4030011600 S.CER C1608 JB 1E 104K-T T 37.4/39.9
C51 4030006860 S.CER C1608 JB 1H 102K-T B 44.4/68
C52 4030011600 S.CER C1608 JB 1E 104K-T T 43.4/65
C53 4030011600 S.CER C1608 JB 1E 104K-T B 43.9/57.2
C54 4030011600 S.CER C1608 JB 1E 104K-T B 36.7/38.6
C55 4030011600 S.CER C1608 JB 1E 104K-T T 54.4/67
C56 4030008560 S.CER C1608 CH 1H 300J-T T 49/48.4
C57 4030008560 S.CER C1608 CH 1H 300J-T T 47.7/48.1
C58 4030006900 S.CER C1608 JB 1H 103K-T B 54.1/39.9
C59 4030011600 S.CER C1608 JB 1E 104K-T T 61.9/40.6
C60 4030011600 S.CER C1608 JB 1E 104K-T T 70.4/40.5
C61 4030007090 S.CER C1608 CH 1H 470J-T B 46.4/51.3
C62 4030007090 S.CER C1608 CH 1H 470J-T B 61.4/45.7
C63 4030007090 S.CER C1608 CH 1H 470J-T B 63.3/46.5
C64 4030007090 S.CER C1608 CH 1H 470J-T B 64.6/41.1
C65 4030007090 S.CER C1608 CH 1H 470J-T B 57.3/38
C66 4030007090 S.CER C1608 CH 1H 470J-T B 57.2/36.7
C67 4030007090 S.CER C1608 CH 1H 470J-T B 71.5/61.3
C68 4030007090 S.CER C1608 CH 1H 470J-T B 70.3/54.4
C69 4030007090 S.CER C1608 CH 1H 470J-T B 66/46.2
C71 4030007090 S.CER C1608 CH 1H 470J-T T 21.6/46
C86 4030006900 S.CER C1608 JB 1H 103K-T B 47.1/49.5
C88 4030006850 S.CER C1608 JB 1H 471K-T B 46.3/71.3
C100 4030006850 S.CER C1608 JB 1H 471K-T B 79.5/40
C101 4030006900 S.CER C1608 JB 1H 103K-T T 106.1/58.6
C102 4030006900 S.CER C1608 JB 1H 103K-T T 110.9/57.2
C103 4030006900 S.CER C1608 JB 1H 103K-T B 113.2/56.4
C104 4030006900 S.CER C1608 JB 1H 103K-T T 113.1/47.2
C105 4030011600 S.CER C1608 JB 1E 104K-T T 84.4/51.4
C106 4030007060 S.CER C1608 CH 1H 270J-T T 94.5/55.9
C107 4030007060 S.CER C1608 CH 1H 270J-T T 94.5/53.1
C108 4030011600 S.CER C1608 JB 1E 104K-T T 103/43.3
C109 4030006900 S.CER C1608 JB 1H 103K-T T 79.8/53.1
C110 4030006900 S.CER C1608 JB 1H 103K-T T 92.5/53.1
C111 4030006900 S.CER C1608 JB 1H 103K-T T 92.5/55.9
C112 4030006900 S.CER C1608 JB 1H 103K-T T 79.8/55.9
C113 4030011600 S.CER C1608 JB 1E 104K-T T 108.5/27.6
C121 4030007050 S.CER C1608 CH 1H 220J-T T 11.9/73.8
C122 4030007050 S.CER C1608 CH 1H 220J-T T 13.5/73.8
C123 4030007050 S.CER C1608 CH 1H 220J-T T 14.9/73.8
C124 4030007050 S.CER C1608 CH 1H 220J-T T 16.3/73.8
C126 4030007050 S.CER C1608 CH 1H 220J-T T 19.1/73.8
C127 4030007050 S.CER C1608 CH 1H 220J-T T 20.5/73.8
C128 4030007050 S.CER C1608 CH 1H 220J-T T 21.9/73.8
C150 4030006900 S.CER C1608 JB 1H 103K-T T 86.5/15.2
C151 4030011600 S.CER C1608 JB 1E 104K-T T 104/10.1
C152 4550006700 S.TAN ECST1AY106R T 105.7/10.9
C153 4030012600 S.CER C2012 JB 1A 105M-T T 91.3/9.3
C154 4030011600 S.CER C1608 JB 1E 104K-T T 91.5/7.7
C155 4030006860 S.CER C1608 JB 1H 102K-T T 100.9/6.4
C156 4030006860 S.CER C1608 JB 1H 102K-T T 104/7.5
C157 4030011600 S.CER C1608 JB 1E 104K-T B 102.9/9.9
C158 4030011600 S.CER C1608 JB 1E 104K-T T 91.1/15.3
C159 4030007130 S.CER C1608 CH 1H 101J-T T 91.4/10.9
C160 4030008890 S.CER C1608 JB 1H 273K-T B 100/6.2
C161 4030008890 S.CER C1608 JB 1H 273K-T B 98.2/8.3
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C162 4030007000 S.CER C1608 CH 1H 090D-T B 93.3/8.5
C200 4030011600 S.CER C1608 JB 1E 104K-T B 34.6/54.2
C202 4610001590 S.TRI TZC3R100A110R00 T 24.6/36.1
C203 4030011600 S.CER C1608 JB 1E 104K-T T 28.1/33.3
C204 4030006980 S.CER C1608 CH 1H 070D-T T 23.7/32.8
C206 4030006900 S.CER C1608 JB 1H 103K-T T 17.3/18.8
C207 4030011600 S.CER C1608 JB 1E 104K-T T 24.2/5.8
C208 4030006900 S.CER C1608 JB 1H 103K-T T 34.2/5.8
C209 4030011600 S.CER C1608 JB 1E 104K-T T 43.5/7.8
C210 4030011600 S.CER C1608 JB 1E 104K-T B 32.1/29.7
C211 4030011600 S.CER C1608 JB 1E 104K-T B 23.4/26.6
C212 4030009650 S.CER C1608 CH 1H 240J-T T 39.3/37
C213 4030006980 S.CER C1608 CH 1H 070D-T B 32.3/33
C214 4030006900 S.CER C1608 JB 1H 103K-T B 38.1/30.3
C215 4610001590 S.TRI TZC3R100A110R00 T 32/33.8
C216 4550006780 S.TAN TEESVB2 0J 476M8R B 48.8/25.6
C300 4550006250 S.TAN TEESVA 1A 106M8L T 56.5/15.4
C301 4030010040 S.CER C1608 JB 1H 561K-T T 59/22.1
C302 4030009490 S.CER C1608 JB 1H 821K-T T 65/19.4
C303 4340000270 S.MLR ECHU 1H 121GB5 T 60.7/16.5
C304 4030007170 S.CER C1608 CH 1H 221J-T T 67.4/14.3
C305 4030007170 S.CER C1608 CH 1H 221J-T T 67.7/15.6
C306 4030007170 S.CER C1608 CH 1H 221J-T T 65/16.8
C307 4030007170 S.CER C1608 CH 1H 221J-T T 65/14.2
C308 4550005980 S.TAN TEESVA 1A 475M8L T 60.3/11.7
C309 4030010760 S.CER C1608 CH 1H 331J-T T 61.8/13.4
C310 4550006250 S.TAN TEESVA 1A 106M8L T 55.2/26.5
C311 4030010040 S.CER C1608 JB 1H 561K-T T 57.6/33.2
C312 4030009490 S.CER C1608 JB 1H 821K-T T 63.6/30.5
C313 4340000270 S.MLR ECHU 1H 121GB5 T 59.4/27.6
C314 4030007170 S.CER C1608 CH 1H 221J-T T 68.1/32.3
C315 4030007170 S.CER C1608 CH 1H 221J-T T 68.1/33.6
C316 4030007170 S.CER C1608 CH 1H 221J-T T 65.5/29.7
C317 4030007170 S.CER C1608 CH 1H 221J-T T 68.1/29.7
C318 4550005980 S.TAN TEESVA 1A 475M8L T 63.4/25.8
C319 4030010760 S.CER C1608 CH 1H 331J-T T 65.1/22.4
C320 4510005600 S.ELE ECEV1CS100SR B 59.6/21.7
C349 4550006250 S.TAN TEESVA 1A 106M8L B 87.7/24.7
C350 4030011600 S.CER C1608 JB 1E 104K-T T 82/20.4
C351 4030011600 S.CER C1608 JB 1E 104K-T T 90.6/26.5
C352 4030011600 S.CER C1608 JB 1E 104K-T T 76.5/22.3
C353 4030011810 S.CER C1608 JB 1A 224K-T T 92.4/27.1
C354 4030011600 S.CER C1608 JB 1E 104K-T T 93.7/27.1
C355 4030006860 S.CER C1608 JB 1H 102K-T T 96.5/23.7
C356 4030006860 S.CER C1608 JB 1H 102K-T T 96.5/22.4
C357 4030011600 S.CER C1608 JB 1E 104K-T T 100.6/26.3
C358 4030006860 S.CER C1608 JB 1H 102K-T T 101.3/21
C359 4030008920 S.CER C1608 JB 1H 473K-T B 85.7/22.7
C360 4030011600 S.CER C1608 JB 1E 104K-T T 104.8/16.4
C361 4030011810 S.CER C1608 JB 1A 224K-T T 93.3/19.7
C362 4030011600 S.CER C1608 JB 1E 104K-T B 85.2/17.8
C363 4030008920 S.CER C1608 JB 1H 473K-T T 82/17.8
C364 4030011600 S.CER C1608 JB 1E 104K-T T 93.3/18.4
C400 4030006850 S.CER C1608 JB 1H 471K-T T 17.6/5.9
C401 4030007090 S.CER C1608 CH 1H 470J-T T 17.6/7.2
C402 4030006900 S.CER C1608 JB 1H 103K-T B 82/17.6
C403 4030007090 S.CER C1608 CH 1H 470J-T B 16.8/19.1
C404 4030007090 S.CER C1608 CH 1H 470J-T B 18.1/18.7
C405 4030007090 S.CER C1608 CH 1H 470J-T B 15.5/19.1
C406 4030007090 S.CER C1608 CH 1H 470J-T B 14.2/19.1
C407 4030007090 S.CER C1608 CH 1H 470J-T T 38.8/68.1
C408 4030007090 S.CER C1608 CH 1H 470J-T B 83.4/10.8
C409 4030007130 S.CER C1608 CH 1H 101J-T B 77.1/14.2
C410 4030007130 S.CER C1608 CH 1H 101J-T T 76.8/17.6
C411 4030007130 S.CER C1608 CH 1H 101J-T B 83.9/17.8
C412 4030007130 S.CER C1608 CH 1H 101J-T B 86.6/13.4
C413 4030007090 S.CER C1608 CH 1H 470J-T T 43.3/68.9
C414 4030007090 S.CER C1608 CH 1H 470J-T B 31.7/65.5
C415 4030007090 S.CER C1608 CH 1H 470J-T B 30.4/65.5
C416 4030007090 S.CER C1608 CH 1H 470J-T B 31.2/68.2
C417 4030007090 S.CER C1608 CH 1H 470J-T B 29.1/65.5
C418 4030007090 S.CER C1608 CH 1H 470J-T B 27.8/65.5
C419 4030007090 S.CER C1608 CH 1H 470J-T B 26.5/65.5
C420 4030007090 S.CER C1608 CH 1H 470J-T B 41.6/74.7
C421 4030007090 S.CER C1608 CH 1H 470J-T B 29.7/71.8
C422 4030007090 S.CER C1608 CH 1H 470J-T B 8.2/15.4
C423 4030007090 S.CER C1608 CH 1H 470J-T B 9.5/15.4
C424 4030007090 S.CER C1608 CH 1H 470J-T B 72/16.8
C425 4030007090 S.CER C1608 CH 1H 470J-T B 71.3/14.2
C426 4030007090 S.CER C1608 CH 1H 470J-T B 73.4/10.7
C427 4030007090 S.CER C1608 CH 1H 470J-T T 74.9/18.1
C428 4030007090 S.CER C1608 CH 1H 470J-T B 76.9/16.9
C429 4030007090 S.CER C1608 CH 1H 470J-T T 78.1/16.8
C430 4030007090 S.CER C1608 CH 1H 470J-T T 79.4/16.8
C431 4030007090 S.CER C1608 CH 1H 470J-T B 87.3/7.2
C432 4030007090 S.CER C1608 CH 1H 470J-T B 80.6/17.6
C433 4030007090 S.CER C1608 CH 1H 470J-T B 80.9/14.2
C434 4030007090 S.CER C1608 CH 1H 470J-T B 80.3/6.5
C435 4030007090 S.CER C1608 CH 1H 470J-T B 82.2/14.2
C437 4030007090 S.CER C1608 CH 1H 470J-T B 84.7/12.4
C438 4030007090 S.CER C1608 CH 1H 470J-T B 22/17.6
C442 4030011600 S.CER C1608 JB 1E 104K-T T 80.7/17.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
