Icom ID-1

[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C443 4030011810 S.CER C1608 JB 1A 224K-T B 71.3/18.6
C500 4510004640 S.ELE ECEV1CA470SP B 84.4/63.5
C501 4030011600 S.CER C1608 JB 1E 104K-T T 84.1/66.4
C502 4030011600 S.CER C1608 JB 1E 104K-T T 86.5/67
C503 4510004640 S.ELE ECEV1CA470SP B 96.2/63.9
C504 4030006850 S.CER C1608 JB 1H 471K-T T 86.5/65.7
C506 4030011600 S.CER C1608 JB 1E 104K-T T 58.6/7.5
C509 4550006250 S.TAN TEESVA 1A 106M8L T 85.3/64
C510 4030011600 S.CER C1608 JB 1E 104K-T T 97.4/17.8
C511 4030011600 S.CER C1608 JB 1E 104K-T T 90.5/64.2
C512 4550006250 S.TAN TEESVA 1A 106M8L T 88.8/64.4
C513 4510007130 S.ELE EEFCD 0J 470R T 98.6/73.1
C514 4030006850 S.CER C1608 JB 1H 471K-T T 109.3/75.9
C515 4510005820 S.ELE ECEV1CA101P B 109.5/63.3
C516 4510005600 S.ELE ECEV1CS100SR B 64.2/76
C517 4030011600 S.CER C1608 JB 1E 104K-T T 66.9/75.3
C518 4030011600 S.CER C1608 JB 1E 104K-T T 64.5/72.5
C519 4550006250 S.TAN TEESVA 1A 106M8L T 65.2/69.9
C520 4550006200 S.TAN ECST0JY106R T 71.7/75.7
C521 4550006200 S.TAN ECST0JY106R B 69.4/64.9
C522 4550006620 S.TAN ECST0JY226R T 96.6/65.7
C550 4030008560 S.CER C1608 CH 1H 300J-T T 4.2/63
C551 4030008560 S.CER C1608 CH 1H 300J-T T 4.2/48
C552 4030011600 S.CER C1608 JB 1E 104K-T B 14.3/57.6
C553 4030011600 S.CER C1608 JB 1E 104K-T B 15.4/53.9
C554 4030011600 S.CER C1608 JB 1E 104K-T T 18.1/56.2
C555 4030008880 S.CER C1608 JB 1H 223K-T T 24/61
C556 4030007070 S.CER C1608 CH 1H 330J-T B 18.7/64.1
C557 4550006200 S.TAN ECST0JY106R T 13/68.2
C558 4030006900 S.CER C1608 JB 1H 103K-T T 10.1/70.3
C559 4030007090 S.CER C1608 CH 1H 470J-T T 84/55.1
C560 4030007090 S.CER C1608 CH 1H 470J-T B 79.5/41.3
C561 4030007090 S.CER C1608 CH 1H 470J-T T 85.7/51.4
C562 4030007090 S.CER C1608 CH 1H 470J-T T 88.3/52.4
C563 4030007090 S.CER C1608 CH 1H 470J-T T 103/42
C564 4030007090 S.CER C1608 CH 1H 470J-T T 99.3/30
C565 4030007090 S.CER C1608 CH 1H 470J-T B 96.2/34.6
C566 4030007090 S.CER C1608 CH 1H 470J-T T 90.6/27.8
C567 4030007090 S.CER C1608 CH 1H 470J-T T 85.4/27.8
C568 4030007090 S.CER C1608 CH 1H 470J-T T 85.4/26.5
C569 4030007090 S.CER C1608 CH 1H 470J-T T 78.8/28.4
C570 4030007090 S.CER C1608 CH 1H 470J-T T 81.7/27.8
C571 4030007090 S.CER C1608 CH 1H 470J-T B 93.2/44.5
C572 4030007090 S.CER C1608 CH 1H 470J-T B 90.3/47.7
C573 4030007090 S.CER C1608 CH 1H 470J-T B 89/47.7
C574 4030007090 S.CER C1608 CH 1H 470J-T T 78.5/55.9
C575 4030007090 S.CER C1608 CH 1H 470J-T T 78.5/53.1
C576 4030007090 S.CER C1608 CH 1H 470J-T T 91.2/53.1
C577 4030007090 S.CER C1608 CH 1H 470J-T T 91.2/55.9
C578 4030007090 S.CER C1608 CH 1H 470J-T B 12.3/49
C579 4030007090 S.CER C1608 CH 1H 470J-T B 10.7/47
J50 6510019270 S.CNR 52365-0691 T 5.1/43.9
J100 6510021290 S.CNR S10B-ZR-SM3A-TF B 18.7/77.2
J101 6510022820 S.CNR AXN430C530P B 17.2/8.8
J300 6510018350 S.CNR S3B-ZR-SM3A-TF T 13.9/12.4
J400 6510022710 S.CNR 30FLZ-SM1-TB T 78/7.7
J401 6510022710 S.CNR 30FLZ-SM1-TB T 35/74.4
DS100 5040002050 LED SPR-39MVWF
DS101 5040002050 LED SPR-39MVWF
DS102 5040002050 LED SPR-39MVWF
T100 5920000800 TSM 20F001N <YCL>
W1 7030003860 S.RES ERJ3GE JPW V T 11.9/20.1
W2 7030003860 S.RES ERJ3GE JPW V B 12.3/31.9
W50 7030003860 S.RES ERJ3GE JPW V T 51.8/67
W51 7030003860 S.RES ERJ3GE JPW V B 47/59.2
W52 7030003860 S.RES ERJ3GE JPW V B 59.2/64.3
W125 7030003860 S.RES ERJ3GE JPW V T 17.7/73.8
W126 7030003860 S.RES ERJ3GE JPW V T 10.4/76.8
W129 7030003860 S.RES ERJ3GE JPW V T 23.3/73.8
W200 7030003860 S.RES ERJ3GE JPW V B 58.3/16
W213 7030003860 S.RES ERJ3GE JPW V B 43.7/29.1
W300 7030003860 S.RES ERJ3GE JPW V T 55.5/5.8
W310 7030003860 S.RES ERJ3GE JPW V T 71.6/21.4
W400 7030003860 S.RES ERJ3GE JPW V B 77.3/12.3
W401 7030003860 S.RES ERJ3GE JPW V B 77.7/7.3
W402 7030003860 S.RES ERJ3GE JPW V B 7.7/34.4
W403 7030003860 S.RES ERJ3GE JPW V B 36/71.1
[LOGIC-1 UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1160 1150002190 IC RA18H1213G1-21
J1 6510004910 CNR NR-DS-E 01
MF1 2710000590 FAN MF40D-12H-001
W1 8900010890 CBL OPC-1115
W2 8900010890 CBL OPC-1115
W3 8900011950 CBL OPC-1224
EP1 6910000630 BEA FSRH070140RN000B
EP20 6910011940 BEA ZCAT2436-1330A-BK-M
[EUR2], [EUR3] only
EP1160 6910000970 BEA DL-2OP 2.6-3-1.2H
EP1162 6910000970 BEA DL-2OP 2.6-3-1.2H
6 - 11
[RC-24] (Optional for some version)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1130009120 S.IC SED1526F0A B 69.5/29.5
IC2 1140007890 S.IC HD64F3644H B 111.8/20.4
IC3 1110005940 S.IC S-80842CLMC-B63-T2 B 127.5/23.9
IC4 1130005720 S.IC TC7W04F (TE12L) B 121/8.2
IC5 1110003390 S.IC AN8005M-(E1) B 67.9/11.6
IC6 1110002860 S.IC TA75S393F (TE85R) B 85.6/7.9
Q1 1530002060 S.TR 2SC4081 T106 R B 133.6/18.1
Q2 1590000720 S.TR DTA144EUA T106 B 120.4/4
Q3 1590000680 S.TR DTC114EUA T106 B 123/2.7
Q6 1590000440 S.TR DTA143ZUA T106 B 90.4/14.6
Q7 1590000440 S.TR DTA143ZUA T106 B 86.9/20.8
Q8 1590000440 S.TR DTA143ZUA T106 B 90.4/17.1
Q9 1590000440 S.TR DTA143ZUA T106 B 90.7/19.7
Q10 1590000680 S.TR DTC114EUA T106 B 93.3/17
Q11 1590000680 S.TR DTC114EUA T106 B 93.3/19.5
Q12 1590000680 S.TR DTC114EUA T106 B 90.4/12.1
Q13 1530002060 S.TR 2SC4081 T106 R B 34/7.1
D1 1790001280 S.DIO MA111 (TX) B 134.1/21.7
D3 1790001280 S.DIO MA111 (TX) B 116.2/2.4
D9 1750000130 S.DIO DA204U T106 B 132.6/10.1
D10 1790001280 S.DIO MA111 (TX) B 126.3/3.8
D11 1790000660 S.DIO MA728 (TX) B 126.2/2
D12 1790001280 S.DIO MA111 (TX) B 129.8/2
D13 1790001280 S.DIO MA111 (TX) B 114.2/8.4
X1 6050011310 S.XTL CR-717 (9.8304 MHz) B 97.4/24.4
L1 6200001720 S.COL NL 322522T-1R0J B 16.2/12.3
R1 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 90.8/40.5
R2 7310002820 S.TRI RV-158 (RH03A3AS5) 474 B 93.7/39.4
R3 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 90/38.6
R4 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 129.3/21.5
R5 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 130.5/24.7
R6 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) B 134/23.5
R7 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 131.7/18.1
R8 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 131.8/20.8
R9 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 133.7/20.1
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 102/15.9
R11 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 100.8/22.2
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 102.3/27.5
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 109.8/10.5
R16 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 118.4/3.9
R17 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 123.2/4.7
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 120.3/13
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 120.3/11.7
R27 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 84.5/23.2
R28 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 87.3/23.2
R29 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 85/20.9
R30 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 93.3/21.7
R31 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 93.3/23
R32 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) B 90.6/23
R34 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) B 88.8/19.9
R35 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/27.1
R36 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/23.2
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/24.5
