6 - 12
[RC-24] (Optional for some version)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/25.8
R39 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/12.8
R40 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/14.1
R41 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/15.4
R42 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/16.7
R43 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/19.3
R44 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/21.9
R45 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 124.2/20.6
R48 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 134.6/10.1
R49 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 114.3/5.3
R51 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 109.8/9.3
R52 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 11.2/36.2
R53 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 7.8/36.2
R54 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 129.4/3.8
R55 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 131.6/4.6
R56 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 88/7.9
R57 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) B 81.9/7.3
R58 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 83.2/7.9
R59 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 90.8/8.5
R60 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 37.3/16.7
R61 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 32.1/7.6
R62 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 30.8/7.6
R63 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) B 36.1/7.6
R64 7030005420 S.RES ERJ3GEYJ 202 V (2 k
Ω
) B 21.6/9.5
R65 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 36.8/9.9
C1 4030011600 S.CER C1608 JB 1E 104K-T B 79.2/40.5
C2 4030011600 S.CER C1608 JB 1E 104K-T B 80.5/40.5
C3 4030011600 S.CER C1608 JB 1E 104K-T B 81.8/40.5
C4 4030011600 S.CER C1608 JB 1E 104K-T B 83.1/40.5
C5 4030011600 S.CER C1608 JB 1E 104K-T B 84.4/40.5
C6 4030012600 S.CER C2012 JB 1A 105M-T B 86.1/30.9
C7 4030012600 S.CER C2012 JB 1A 105M-T B 82.4/31.2
C8 4030008630 S.CER C1608 JF 1H 104Z-T B 77.4/40.5
C9 4030006860 S.CER C1608 JB 1H 102K-T B 81.4/28.8
C10 4030009000 S.CER C2012 JB 1C 224K-T B 130.9/23.1
C11 4030006900 S.CER C1608 JB 1H 103K-T B 100.1/15.1
C12 4550003220 S.TAN TEESVA 1E 105M8L B 97.4/14.8
C13 4030007030 S.CER C1608 CH 1H 150J-T B 100.8/25.6
C14 4030007030 S.CER C1608 CH 1H 150J-T B 100.8/19.5
C15 4030006860 S.CER C1608 JB 1H 102K-T B 107.8/9.7
C16 4030006900 S.CER C1608 JB 1H 103K-T B 109.8/8.1
C17 4030008630 S.CER C1608 JF 1H 104Z-T B 119.7/28.3
C18 4030008630 S.CER C1608 JF 1H 104Z-T B 74.5/11.5
C19 4030006850 S.CER C1608 JB 1H 471K-T B 73.2/11.5
C20 4550006250 S.TAN TEESVA 1A 106M8L B 71.5/12.3
C21 4550003220 S.TAN TEESVA 1E 105M8L B 64.4/12.1
C22 4030008630 S.CER C1608 JF 1H 104Z-T B 62.7/11.3
C23 4030006850 S.CER C1608 JB 1H 471K-T B 61.4/11.3
C24 4030006850 S.CER C1608 JB 1H 471K-T B 60.1/11.3
C25 4030006850 S.CER C1608 JB 1H 471K-T B 51.9/7.6
C26 4030008630 S.CER C1608 JF 1H 104Z-T B 117.1/5.4
C27 4030006860 S.CER C1608 JB 1H 102K-T B 5.2/9.8
C28 4030007090 S.CER C1608 CH 1H 470J-T B 6.5/9.8
C30 4030006860 S.CER C1608 JB 1H 102K-T B 9.1/9.8
C32 4030007090 S.CER C1608 CH 1H 470J-T B 92.1/4.3
C34 4030007090 S.CER C1608 CH 1H 470J-T B 28.8/3.2
C35 4030007090 S.CER C1608 CH 1H 470J-T B 41.9/4.2
C36 4030007090 S.CER C1608 CH 1H 470J-T B 54.9/4.2
C37 4030007090 S.CER C1608 CH 1H 470J-T B 67.9/4.2
C38 4030007090 S.CER C1608 CH 1H 470J-T B 77.3/4.2
C39 4030007090 S.CER C1608 CH 1H 470J-T B 94.1/30.2
C40 4030007090 S.CER C1608 CH 1H 470J-T B 99.5/16.8
C41 4030007090 S.CER C1608 CH 1H 470J-T B 110/35.9
C42 4030007090 S.CER C1608 CH 1H 470J-T B 114.3/31.2
C43 4030007090 S.CER C1608 CH 1H 470J-T B 116.9/31.2
C44 4030007090 S.CER C1608 CH 1H 470J-T B 109.5/5.4
C45 4030007090 S.CER C1608 CH 1H 470J-T B 118/36.9
C46 4030007090 S.CER C1608 CH 1H 470J-T B 115.6/31.2
C47 4030007090 S.CER C1608 CH 1H 470J-T B 118.2/31.2
C48 4030007090 S.CER C1608 CH 1H 470J-T B 115.7/6.2
C49 4030007090 S.CER C1608 CH 1H 470J-T B 128.6/36.9
C50 4030007090 S.CER C1608 CH 1H 470J-T B 126.9/28.1
C51 4030007090 S.CER C1608 CH 1H 470J-T B 127.2/17.6
C52 4030007090 S.CER C1608 CH 1H 470J-T B 128.7/5.4
C53 4510004440 S.ELE ECEV1HA010SR B 26.8/7
C54 4510004440 S.ELE ECEV1HA010SR B 41.9/8.8
C55 4510005300 S.ELE ECEV1AA330SR B 41.2/14.2
C56 4510005300 S.ELE ECEV1AA330SR B 32/12.7
C57 4030006860 S.CER C1608 JB 1H 102K-T B 21.6/7.8
C59 4030007090 S.CER C1608 CH 1H 470J-T B 53.9/10.3
C60 4030007090 S.CER C1608 CH 1H 470J-T B 72.1/7.8
C61 4030011600 S.CER C1608 JB 1E 104K-T B 80.6/9.1
C62 4030007130 S.CER C1608 CH 1H 101J-T B 85.6/5.6
C63 4030006900 S.CER C1608 JB 1H 103K-T B 34.1/9.1
C64 4030006900 S.CER C1608 JB 1H 103K-T B 38.4/7.4
J1 6450001470 CNR 95003-2881 T 9.7/6.1
J2 6510019420 S.CNR B8B-ZR-SM3-TF B 53.4/16.7
J3 6510019270 S.CNR 52365-0691 B 94.5/10.5
[RC-24] (Optional for some versions)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
DS2 5040002470 S.LED FY1112H T 31/26.4
DS3 5040002470 S.LED FY1112H T 42.5/26.4
DS4 5040002470 S.LED FY1112H T 54/26.4
DS5 5040002470 S.LED FY1112H T 65.5/26.4
DS6 5040002470 S.LED FY1112H T 77/26.4
DS7 5040002030 S.LED CL-170Y-CD-T T 94/26.4
DS8 5040002030 S.LED CL-170Y-CD-T T 124.7/31.6
DS10 5040002030 S.LED CL-170Y-CD-T T 124.7/10.6
DS11 5040002030 S.LED CL-170Y-CD-T T 113.7/31.6
DS13 5040002030 S.LED CL-170Y-CD-T T 113.7/10.6
DS14 5040002030 S.LED CL-170Y-CD-T T 34.5/4.2
DS15 5040002030 S.LED CL-170Y-CD-T T 60.5/4.2
DS16 5040002030 S.LED CL-170Y-CD-T T 86.5/4.2
S21 2250000270 ECR RH90N74E20-16F-1738 T 9.5/32.2
W3 7030000010 S.RES MCR10EZHJ JPW (000) T 124.7/21.1
W4 7030000010 S.RES MCR10EZHJ JPW (000) T 113.7/21.1
EP20 6910014690 S.BEA MPZ1608S221A-T B 49.6/11
EP21 6910014690 S.BEA MPZ1608S221A-T B 51.1/11
EP22 6910014690 S.BEA MPZ1608S221A-T B 53.4/11.6
EP23 6910014690 S.BEA MPZ1608S221A-T B 29.9/20
EP24 6910014690 S.BEA MPZ1608S221A-T B 26.5/20.8
EP25 6910014690 S.BEA MPZ1608S221A-T B 58.6/11.1
EP26 6910014690 S.BEA MPZ1608S221A-T B 48.2/11
EP27 6910014690 S.BEA MPZ1608S221A-T B 55.7/11
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
To Next Page
