DGX-IP1000C/IP100H -V1.0
45
STEP 6: DEMONSTRATION
STEP 6-1 TALKING TO AN IP100H USER
STEP 6-2 SEND A MESSAGE TO AN IP100H USER
STEP 6-3 USING THE LOCATION WINDOW
STEP 6-1 TALK ING TO AN IP100H USER
When calling from the IP100FS to TR 1 (IP100H)
(1) Turn ON TR 1’s power, and start up the IP100FS.
(2) Click [TR1] on the IP100FS to select the IP100H that you want to call.
(3) Click and hold IP100FS’s [PTT], and then speak into the microphone at a normal voice level.
The IP100FS displays the following screen, and your voice is heard from TR 1’s speaker.
After speaking, release IP100FS’s [PTT] to listen.
(4) Hold down TR 1 (IP100H)’s [PTT], and then speak into the microphone at a normal voice level.
The IP100FS displays the following screen, and then your voice is heard from the headset via through
IP100FS.
After speaking, release TR 1’s [PTT].
IP100FS
TR 1
Access point
IP1000C
Click the IP100H that you want to call.
The background lights red while making a
call.
The action, type of call and ID are
displayed.
Click and hold IP100FS’s
[PTT] to speak to the target
user.
The background lights green while receiving
a call.
The action, type of call and ID are
displayed.
STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6
