When calling from TR 1 (IP100H) to the IP100FS
(1) Turn ON TR 1’s power (IP100H), and start up the IP100FS.
(2) Push to select the IP100FS’s ID.
While pushing and holding TR 1’s [PTT], speak into the microphone at a normal voice level.
The IP100FS displays the following screen, and then your voice is heard from the headset through the
IP100FS.
After speaking, release TR 1’s [PTT].
(3) While clicking and holding the IP100FS’s [PTT], speak into the microphone at a normal voice level.
The IP100FS displays the following screen, and then your voice is heard from TR 1’s speaker.
After speaking, release IP100FS’s [PTT].
IP100FS
TR 1
Access point
IP1000C
The background lights green while receiving
a call.
The action, type of call and ID are
displayed.
The background lights red while making a
call.
The action, type of call and ID are
displayed.
Click and hold IP100FS’s
[PTT] to speak to the target
users.
