Icom IP100H - Page 50

DGX-IP1000C/IP100H -V1.0
47
STEP 6-2 SEND A MESSAGE TO THE IP100H OPERATOR
When sending a message from an IP100FS to a TR 1 (IP100H)
(1) Turn ON TR 1’s power (IP100H), and start up the IP100FS.
(2) Click the message combo box, and then a drop-down list appears.
(3) Select the desired message from the list.
(4) Click [TR1] on the IP100FS to select the desired IP100H that you want to send a message to.
(5) Click IP100FS’s [PTT] to send the message.
IP100FS
TR 1
Access point
IP1000C
Sending a message!
A drop-down list appears
The selected message is displayed.
Click the desired button that you want to send
a message to.
Click IP100FS’s [PTT], and
the message is sent.
