NXDN™ IC-F5400D/IC-F6400D SERIES PRODUCT GUIDE
9
Model name IC-F5400D IC-F6400D
Version
#01, #11 #01, #11, #21, #31
Destination
USA-01, USA-11
USA-01, USA-11, USA-21,
USA-31
GENERAL
Frequency coverage
136 ~ 174 MHz
380 ~ 470 MHz
450 ~ 512 MHz
Number of conventional channels
1,024 ch/128 zones [IC-F5400D, IC-F6400D]
4,000 ch/128 zones [The license is activated.]
99 ch [IC-F5400DS/IC-F6400DS]
Type of emission
A: 11K0F3E (15.0 kHz)
D: 4K00F1E, D (6.25 kHz); 8K30F1E, D (12.5 kHz)
Intermediate frequency
1st: 49.95 MHz, 2nd: 450 kHz
Power supply voltage
13.6 V DC nominal Negative ground
Current drain
(approximately)
TX
High
9.0 A typical (at 50 W) 8.8 A typical (at 45 W)
Low (at 25 W)
5.0 A typical
RX
Maximum audio
900 mA typical
(Internal speaker)
800 mA typical
(Internal speaker)
Stand by
370 mA typical 270 mA typical
Antenna impedance
50  nominal
Microphone impedance
600 
Audio impedance
4 
Operating temperature range
–30 °C ~ +60 °C; –22 °F ~ +140 °F
Dimensions (W  H  D)
(Projections not included)
174

55

150 mm;
6.8  2.2  5.9 inches
Weight (approximately)
1.5 kg; 3.3 lb
TRANSMITTER
Output power (at 13.6 V DC)
50 W 45 W
Modulation
Frequency modulation, FSK modulation
Maximum frequency deviation
A: ±2.5 kHz
Frequency error
±1.0 ppm
Spurious emissions
90 dB typical 80 dB typical
Adjacent channel power
A: 66 dB typical
D: 66 dB typical (6.25 kHz),
67 dB typical (12.5 kHz)
Audio harmonic distortion
0.5% typical @ AF 1 kHz 40% deviation
FSK error
1% typical (D: 6.25 kHz/12.5 kHz)
FM hum and noise (without CCITT filter)
54 dB typical
Limitation characteristics of the modulator
70% ~ 100% of max. deviation
A: Analog
D: Digital
1-2 IC-F5400D/IC-F6400D’S SPECIFICATIONS
