ICON PRO-FORM SPORT POWER STACK XT - Part Identification Chart

6
M8 Washer
(59)
M10 Washer
(57)
M8 Locknut
(58)
M6 Washer
(82)
Large Washer (17)
10mm Spacer
(61)
13mm Spacer
(52)
M12 Nut (13)
M6 Locknut
(33)
M10 Locknut
(56)
M8 x 20mm
Screw (84)
M4 x 19mm
Self-tapping
Screw (69)
M8 x 20mm
Shoulder Bolt (65)
M10 x 20mm
Screw (72)
M4 x 13mm
Screw (94)
M4 x 25mm
Self-tapping
Screw (85)
M6 x 16mm
Screw (62)
M10 x 25mm
Screw (77)
Use the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in the hard-
ware kit, check to see if it has been preattached.
PART IDENTIFICATION CHART
