6
PART IDENTIFICATION CHART
M6 Washer
(21)
M8 x 68mm Carriage Bolt (20)
M10 Curved
Washer (26)
M8 Curved
Washer (23)
M8 x 68mm Bolt (24)
M8 x 77mm Bolt (28)
M10 x 50mm Screw (19)
M6 x 73mm Screw (18)
M6 x 16mm
Screw (27)
M8 x 75mm Bolt (17)
M8 Locknut
(22)
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in
the hardware kit, check to see if it has been preassembled. Extra parts may be included.
