Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 103 -
Step 3 Double-click the name of the module to open the Configure Server (UDP) dialog box, and
modify the basic settings as necessary, e.g., the IP, Mask and Gateway addresses, and then click the
"OK" button to save the new settings.
Step 4 Reset the Init/Run switch on the tGW-700/GW-2200
module to the "Run" position and reboot the device.
Step 5 Log in to the web configuration pages for the tGW-700/GW-2200 module, using the default
web password, "admin".
