GW-2200 Series
4. Verify that the System (S1) LED indicator
is flashing.
Red, OK
Host PC
Hub/Switch(NS-205)
Power Supply
(+12~+48V DC )
Ethernet Cable
Uses Non-PoE
Switch
Red, OK
