+12 to +48 VDC Jack Power Supply (Non-PoE)
tGW-700 Series
tGW-700-T Series
Host PC
Hub/Switch (NS-205)
CA-002
Power Supply
(+12~+48V DC )
Uses Non-PoE
Switch
Ethernet Cable
Hub/Switch(NS-205)
Host PC
Power Supply
(+12~+48V DC )
Ethernet Cable
