Manufacturers Number (Mfr No --SeeRatingPlate)
ALL Models (*8MPL)
Specifications
*8MPL
050B12
*8MPL
075B12
*8MPL
075F16
*8MPL
100F20
*8MPL
100J20
*8MPL
125J20
General
Input(Btuh)
Output(Btuh)
Temp. Rise (
°
F)
50,000
40,000
35--65
75,000
60,000
30--60
75,000
60,000
30--60
100,000
81,000
35--65
100,000
81,000
35--65
125,000
101,000
35--65
Electrical(Volts/Hz) 115/60 115/60 115/60 115/60 115/60 115/60
RatingPlate Amps. 8.8 9.5 10.1 13.9 12.6 13.9
GasType Nat LP Nat LP Nat LP Nat LP Nat LP Nat LP
Transformer Size (VA)
T’statHeat Anticipator
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
40
.30
Gas & Ignition
Std. Main Orifices (No/Size)
2/#42 2/#54 3/#42 3/#54 3/#42 3/#54 4/#42 4/#54 4/#42 4/#54 5/#42 5/#54
GasValve Honeywell SV
Regulation Type
ManifoldPress.(Inch’sWC)
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
Pilot Orifice Size .018 .011 .018 .011 .018 .011 .018 .011 .018 .011 .018 .01 1
Ignition Type/Series
Lock--Out Time
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
Combustion
Flue OutletSize(Inches)
4
4 4
4 4
4
Limits& Controls
ThermalSensor (
°
F)
LimitControl
Auxiliary Limit (
°
F)
300
See PartsList
130
300
See PartsList
130
300
See PartsList
130
300
See PartsList
130
300
See PartsList
130
300
See PartsList
130
Std.PressureSw.(PartNo)
Press(Close)
Press(Open)
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
Fan Control(Type)
Fan Control On delay
(Timed--secs) Offdelay
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
Blower Data
Type & Size
MotorAmps/Rpm
MotorType/H.p.
Cap. Mfd/Volts
Filter Type
Filter Size (²) (Not Supplied)
1600 CFM and over#
Min.Cool Cap. (Tons)
Max.Cool Cap. (Tons)
11--8
10.3/1100
PSC/
1
/
2
10/370
Washable
14x25x1
-- --
1.5
3
11--8
8/1050
PSC/
1
/
2
7.5/370
Washable
14x25x1
-- --
1.5
3
11--10
10.3/1100
PSC/
1
/
2
10/370
Washable
16x25x1
16x25x1(2)
3
4
11--10
10/1050
PSC/
1
/
2
10/370
Washable
16x25x1
16x25x1(2)
3
5
11--10
11.9/900
PSC/
1
/
2
10/370
Washable
20x25x1
16x25x1(2)
3
5
11--10
10/1050
PSC/
1
/
2
10/370
Washable
20x25x1
16x25x1(2)
3
5
Gas Conversion Kits
Nat toLP NAHL002LP or *1160991
LP to Nat NAHF002NG, *1009510
* Mustbe orderedfrom Service Parts
# Two side filter racks (left and right) required for upflow applications. Side returns are not permitted with downflow or horizontal furnace applications.
