ICP C8MPN - Page 42

Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
Exterrnal Static Pressure
Inches of W.C.
42
441 01 2611 06
THIS DATA IS SUBJECT TO CHANGE WITHOUT NOTICE
15. Circulation Air Blower Data
N8MPN/L050B12 & *8MPN/L050B12 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 472 704 1167 1387
.30 365 638 1102 1288
.50 290 572 1035 1194
.70 209 522 939 1070
.90 463 443 820 937
1.00 413 370 753 858
N8MPN/L075B12 & *8MPN/L075B12 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 695 963 1220 1559
.30 644 928 1183 1463
.50 588 873 1118 1361
.70 540 771 1017 1239
.90 463 675 900 1083
1.00 413 615 835 998
N8MPN/L075F16 & *8MPN/L075F16 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 598 841 1427 1861
.30 400 748 1384 1770
.50 289 667 1343 1677
.70 236 582 1254 1547
.90 -- -- -- 477 1129 1360
1.00 -- -- -- 436 1016 1262
N8MPN100F14 & *8MPN100F14 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 770 949 1328 1760
.30 648 873 1235 1675
.50 544 772 1115 1551
.70 457 684 1036 1404
.90 361 572 895 1215
1.00 308 507 811 1093
N8MPN/L100F20 & *8MPN/L100F20 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 831 1125 1582 2216
.30 814 1123 1588 2179
.50 781 1117 1577 2074
.70 717 1053 1541 1909
.90 609 964 1373 1745
1.00 561 888 1307 1641
NOTE: 075F16 -- Reduce airflow by 5% if bottom return only
100F20 -- Reduce airflow by 10% if bottom return only
125J20 -- Reduce airflow by 5% if bottom return only
*8MPN/L100J20 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 773 1045 1453 2147
.30 755 1037 1469 2128
.50 712 1020 1459 2078
.70 647 979 1424 1963
.90 554 894 1347 1795
1.00 497 828 1262 1705
N8MPN/L100J22
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 1785 1997 2292 2519
.30 1741 1941 2206 2410
.50 1674 1861 2097 2284
.70 1581 1749 1965 2121
.90 1428 1597 1793 1928
1.00 1326 1478 1667 1814
N8MPN/L125J20 & *8MPN/L125J20 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 860 1149 1666 2147
.30 836 1158 1577 2126
.50 805 1140 1561 2148
.70 758 1081 1516 1922
.90 661 1009 1428 1767
1.00 614 925 1357 1663
N8MPN/L125J22
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 1901 2121 2362 2463
.30 1833 2033 2244 2385
.50 1745 1936 2100 2217
.70 1624 1773 1894 2033
.90 1442 1569 1714 1821
1.00 1329 1455 1583 1685
*8MPN150J20 * Denotes Brand
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5²
²²
² WC ESP)
TAP LOW MED L MED H HIGH
.10 1656 1915 2168 2385
.30 1583 1787 2090 2335
.50 1507 1697 1997 2212
.70 1390 1596 1856 2085
.90 1212 1445 1654 1898
1.00 1125 1337 1561 1777
NOTE: N8MPN/L125J22 -- Reduce airflow by 10% if bottom return only
*8MPN/L150J20 -- Reduce airflow by 10% if bottom return only
