Downflow Configurations − continued
L11F063
Representative drawing only, some models may vary in appearance.
Requires Accessory Internal Vent Kit
See Specification Sheets for current kit number
DOWNFLOW VERTICAL − VENT CONFIGURATION
* See NOTES following figures.
Figure 53 Horizontal Left Configurations
HORIZONTAL LEFT − VERTICAL VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
HORIZONTAL LEFT − LEFT VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
Horizontal Left Configurations − continued
HORIZONTAL LEFT − RIGHT VENT CONFIGURATION*
* Requires accessory Internal Vent Kit
Representative drawing only, some models may vary in appearance.
* See NOTES following figures.
Figure 54 Horizontal Right Configurations
HORIZONTAL RIGHT − VERTICAL VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
HORIZONTAL RIGHT − LEFT VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
* See NOTES following figures.
