ICP ICARUS Series - Rx Heavy; Technical Data

116 117
Power LED
Active LED
Data LED
RF LED
RX HEAVYRX HEAVY
RX HEAVY
4.1 TECHNICAL DATA
Frequency 433MHz
Sensitivity -110dBm
Number of channels 6
Number of transmitters max. 24
Number of outputs 12+2 (digital)
Number of inputs 2 (digital)
Max. switching capacity 2.5 A (per output)
Reaction time < 40ms
Antenna Internal
IP protection rating IP 67
Voltage 9-30Vdc
Energy consumption < 1W (no output active)
Max. current 10 A
Dimensions 204 × 124 × 91mm
Weight 450g (without connection cable)
Work area:
Range Approx. 100m (depending on surroundings)
Temperature -30°C bis +70°C
Air humidity 10% - 95%
Housing material ABS
Working altitude < 2000m above NN
124
204
91
Output LEDs
